| Company | SATCO |
|---|---|
| Ballasting Requirements | Dimmable only with a Compatible Dimmable Ballast (See Ballast Compatibility Chart); Direct Replacement-for use on Electronic ballasts with no rewiring required |
| Dimmable Text | Only in Type A mode; Check Ballast MFG for Dimmer Compatibility |
| Lamp Filament | LED |
| Fixture Type | PL |
| Status | Obsolete |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | White |
| Additional Info | Replaces 18, 26, 32, and 42 watt CFL-s; No re-wiring needed; Instant on to full brightness / no flickering; Horizontal operation; Up to 70% energy saving |
| Amps | 0.108-0.047A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | Frost |
| Lensed | Yes |
| Operating Position | Universal |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Fluor Equiv | 28W |
| Incandescent Equivalent | 100W |
| CCT (Kelvin Temp) | 2700K |
|---|---|
| Dimmable | Yes-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 120 |
| Color Temp | Warm White |
| CRI | 80+ |
| Dimming Type | Check Ballast MFG for Dimmer Compatibility, Only in Type A mode |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Lumens | 900L |
| Volts | 120V-277V |
| Watts | 13W |
| Lamp Base | G24q (4-Pin) |
|---|---|
| Finish | Frost |
| Housing Color | White |
| ANSI Base | G24q |
| Lamp Type | PL |
| MOD Lamps | 1.75 |
| MOL | 5.25 |
| Warranty | 5-Years |
|---|
| FCC Compliant | Yes |
|---|---|
| Location Rating | Damp |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Classified |
| California Ban | Lawful for sale |
| DLC Approved | No |
| Title 20 | Exempt |
| T24 Compliant | No |
| UPC | 045923093081 |
|---|---|
| Case Cube | 0.5746 |
| Case Height | 15.6 |
| Case Length | 9.5 |
| Case Quantity | 50 |
| Case UPC | 10045923093088 |
| Case Weight | 16.39 |
| Case Width | 6.7 |
| EA Cube | 0.0061 |
| EA Height | 1.61 |
| EA Length | 5.22 |
| EA Quantity | 1 |
| EA Weight | 0.3 |
| EA Width | 1.26 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Box |
| Web Length | 5.25 |
| Web Width | 1.75 |
