Status | Discontinued |
Substitute | S33113 |
Watts | 80W |
Incandescent Equivalent | 400W |
HID Equivalent | 250W |
Volts | 120V-277V |
Shape | HB60 |
Base | Mogul Extended |
ANSI Base | EX39 |
Finish | Translucent White |
CCT (Kelvin) | 5000K |
Temperature | Natural Light |
CRI | 80+ |
Lumens | 10000L |
Beam Spread | 115 |
Dimmable | Non-Dimmable |
Hours Rated | 50000 |
Product Category | Hi-Bay |
Lamp Type | Hi-Bay |
Technology | LED |
Min Compartment Size | Length: 13.5 in. Width: 13.5 in. Height: 12 in. |
Ballasting Requirements | Ballast Bypass |
Watts | 80W |
Incandescent Equivalent | 400W |
HID Equivalent | 250W |
Volts | 120V-277V |
Ballasting Requirements | Ballast Bypass |
Operating Frequency | 50-60Hz |
CCT (Kelvin) | 5000K |
Temperature | Natural Light |
CRI | 80+ |
Lumens | 10000L |
Candlepower | 3000 |
Beam Spread | 115 |
Dimmable | Non-Dimmable |
Power Factor | 0.98/0.92 |
Hours Rated | 50000 |
Operating Position | Universal |
Surge Protection | Built-in surge protection - 6KV |
Operating Temperature | -40C (-40F) to +60C (+140F) |
MOL | 10.12 |
MOD | 7.48 |
Shape | HB60 |
Base | Mogul Extended |
ANSI Base | EX39 |
Finish | Translucent White |
Lens Finish | Translucent White |
Housing Color | White |
Weight (lb.) | 1.72 |
Min Compartment Size | Length: 13.5 in. Width: 13.5 in. Height: 12 in. |
Rated For Enclosed Fixture | Yes |
Installation Notes | Not for use in vapor tight fixtures. |
Warranty | 5-Years |
Safety Listing | cULus - Classified; cULus - Certified |
Location Rating | Damp |
DLC Approved | No |
RoHS Compliant | Yes |
FCC Compliant | Yes |
SDS Sheet | LED Lamp |
Each UPC | 045923131134 |
Each Quantity | 1 |
Each Length (in.) | 7.48 |
Each Width (in.) | 7.48 |
Each Height (in.) | 10.43 |
Each Weight (lb.) | 2.16 |
Each Cube (CuFt.) | 0.3377 |
Pack Type | Box |
Inner Quantity | 0 |
Inner Length (in.) | 0.00 |
Inner Width (in.) | 0.00 |
Inner Height (in.) | 0.00 |
Inner Weight (lb.) | 0.00 |
Inner Cube (CuFt.) | 0.0000 |
Case UPC | 10045923131131 |
Case Quantity | 4 |
Case Length (in.) | 15.87 |
Case Width (in.) | 15.75 |
Case Height (in.) | 11.69 |
Case Weight (lb.) | 10.25 |
Case Cube (CuFt.) | 1.6909 |
