| Status | Discontinued |
| Substitute | S16431 |
| Watts | 9W |
| Incandescent Equivalent | 40W |
| Fluorescent Equivalent | 35W |
| Volts | 120V-277V |
| Ballast Type | Type B |
| Shape | T8 |
| Base | Recessed Double Contact HO/VHO |
| ANSI Base | R17d |
| Nominal Length | 24 |
| Finish | Frost |
| CCT (Kelvin) | 6500K |
| Temperature | Daylight |
| CRI | 80+ |
| Lumens | 1200L |
| Beam Spread | 360 |
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Product Category | Linear |
| Lamp Type | Linear |
| Technology | LED |
| Watts | 9W |
| Incandescent Equivalent | 40W |
| Fluorescent Equivalent | 35W |
| Volts | 120V-277V |
| Ballasting Requirements | Ballast Bypass |
| Ballast Type | Type B |
| Operating Frequency | 50/60Hz |
| CCT (Kelvin) | 6500K |
| Temperature | Daylight |
| CRI | 80+ |
| Lumens | 1200L |
| Beam Spread | 360 |
| Dimmable | Non-Dimmable |
| Power Factor | 0.9 |
| Hours Rated | 50000 |
| Operating Temperature | -30C (-22F) to +45C (+113F) |
| MOL | 21.88 |
| MOD | 1 |
| Nominal Length | 24 |
| Shape | T8 |
| Base | Recessed Double Contact HO/VHO |
| ANSI Base | R17d |
| Finish | Frost |
| Material | Plastic |
| Lens Finish | Frost |
| Weight (lb.) | 0.36 |
| Installation Notes | Not for use in vapor tight fixtures. No ballast or external driver required; Direct wire 120-277V line voltage; Single ended wiring |
| Rated For Enclosed Fixture | Yes |
| Warranty | 5-Years |
| Safety Listing | cULus - Classified; cULus - Certified; cRUus - Recognized Component; ETLus - Sanitation Recognized Component |
| Location Rating | Damp |
| DLC Approved | No |
| UL Application | Tubes |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| NSF Approved | Yes |
| SDS Sheet | LED Lamp |
| Each UPC | 045923164019 |
| Each Quantity | 1 |
| Each Length (in.) | 23.46 |
| Each Width (in.) | 1.00 |
| Each Height (in.) | 1.00 |
| Each Weight (lb.) | 0.44 |
| Each Cube (CuFt.) | 0.0136 |
| Pack Type | Egg Crate |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923164016 |
| Case Quantity | 10 |
| Case Length (in.) | 24.00 |
| Case Width (in.) | 7.56 |
| Case Height (in.) | 4.92 |
| Case Weight (lb.) | 4.40 |
| Case Cube (CuFt.) | 0.5166 |
