| Company | SATCO |
|---|---|
| Center Beam Candle Power | 4650 |
| Dimmable Text | Check the transformer/driver MFG for dimmer compatibility |
| Lamp Filament | AX |
| Fixture Type | MR |
| Spot Type | NSP - Narrow Spot |
| Status | Obsolete |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | No Finish |
| Additional Info | UV Block |
| Amps | 1.667A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | None |
| Lensed | No |
| Operating Position | Universal |
| SDS Class | Halogen_Double_Ended_or_Pin_Based_Lamp |
| Product Technology | Halogen |
| CCT (Kelvin Temp) | 2900K |
|---|---|
| Dimmable | Yes-Dimmable |
| Hours Rated | 4000 |
| Beam Angle (degree) | 10 |
| Color Temp | Warm White |
| CRI | 100 |
| Lumens | 250L |
| Volts | 12V |
| Watts | 20W |
| Lamp Base | Miniature 2 Pin Round |
|---|---|
| Finish | None |
| Housing Color | Clear |
| ANSI Base | GU5.3/GX5.3 |
| Lamp Type | MR16 |
| MOD Lamps | 2.0 |
| MOL | 1.75 |
| CA T20 Compliant Substitute | S9491 |
|---|---|
| MA Alt Sub | S9552 |
| NV Alt Sub | S9552 |
| ROHS Compliant | Yes |
| Safety Listing | Not Applicable |
| California Ban | Non-Compliant |
| DLC Approved | No |
| Title 20 | No |
| T24 Compliant | No |
| US State Ban | CA, MA, NV |
| UPC | 046135583148 |
|---|---|
| Case Cube | 0.1145 |
| Case Height | 4.84 |
| Case Length | 9.53 |
| Case Quantity | 20 |
| Case UPC | 10046135583145 |
| Case Weight | 1.81 |
| Case Width | 4.29 |
| EA Cube | 0.0039 |
| EA Height | 2.17 |
| EA Length | 1.77 |
| EA Quantity | 1 |
| EA Weight | 0.1 |
| EA Width | 1.77 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Box |
| Web Length | 1.75 |
| Web Width | 2.0 |
