Lights

S29391

22W/LED/HID/5000K/100-277V E26

22W LED HID Replacement; 5000K; Medium base; 100-277V

Lights

S29391

22W/LED/HID/5000K/100-277V E26

22W LED HID Replacement; 5000K; Medium base; 100-277V

Specifications

General
StatusDiscontinued
Watts22
Incandescent Equivalent150
Fluorescent Equivalent40
HID Equivalent100
Volts100V-277V
ShapeCorncob
BaseMedium
ANSI BaseE26
CCT (Kelvin)5000
TemperatureNatural Light
CRI80+
Lumens2950
Beam Spread300
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeCorncob
TechnologyLED
Min Compartment SizeLength 8.5 in. Width 6 in. Depth 6 in.
Ballasting RequirementsBallast by-pass - Direct wire only 100 - 277V
Electrical
Watts22
Incandescent Equivalent150
Fluorescent Equivalent40
HID Equivalent100
Volts100V-277V
Ballasting RequirementsBallast by-pass - Direct wire only 100 - 277V
Working VoltageAC 90-305V
Operating Frequency50/60Hz
CCT (Kelvin)5000
TemperatureNatural Light
CRI80+
Lumens2950
Beam Spread300
DimmableNon-Dimmable
Dimmable Down ToN/A
Dimming TypeN/A
Power Factor>0.90
Hours Rated50000
Burning PositionUniversal
Operating Temperature-20C (-4F) to a maximum of +40C (+104F)
Physical
MOL7.56
MOD2.75
ShapeCorncob
BaseMedium
ANSI BaseE26
Weight0.96
Additional Information
Additional InfoReplaces HID, CFL, and Incandescent;|UL approved for totally enclosed fixtures;|For outdoor & indoor use;|Emits no UV light / Contains no Mercury (Hg)
Min Compartment SizeLength 8.5 in. Width 6 in. Depth 6 in.
IP RatingIP65
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus - Damp
Energy StarNo
CEC StatusLawful for sale in California
RoHS CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923293917
Each Quantity1
Each Length3.38
Each Width3.38
Each Height7.71
Each Weight1.15
Each Cube0.05
Pack TypeBox
Inner UPC20045923293911
Inner Quantity12
Inner Length14.37
Inner Width10.94
Inner Height8.50
Inner Weight14.62
Inner Cube0.75
Case UPC10045923293914
Case Quantity24
Case Length15.16
Case Width11.61
Case Height20.08
Case Weight31.30
Case Cube1.98
×

Dimmer Compatibility

×

Precautions

No precautions available at this time.
