S29563

4.5G25/CL/LED/E26/27K/120V

Discontinued - Suggested Replacement: S21226
  • 4.5 Watt G25 LED Filament
  • Clear
  • Medium base
  • 2700K
  • 450 Lumens
  • 120 Volt
location_rating^damp^1
dimmable^dimmable^2
rated_for_enclosed_fixture^true^2
hours_rated^15k^2
volts^120v^2
fcc_compliant^true^3
rohs_compliant^y^3
S29563 SpecificationsS29563 LFLSA1980 LEDFilamentLamps FullLine low res 8 3 22
Tools
Lighting Layout Analysis For S29563
Create your own analysis for this Part Number
Custom Lighting Layout Analysis
Request a lighting layout
Description
Description
4.5 Watt G25 LED Filament; Clear; Medium base; 2700K; 450 Lumens; 120 Volt
Products Specs
General
CompanySATCO
Lamp FilamentLED Filament
Fixture TypeGlobe
Product NotesReplaces up to 40 watt lamps; Shatterproof option available on request
StatusDiscontinued
Most Current GenerationS21226
CCT SelectableFalse
Wattage SelectableFalse
Finish FamilyNo Finish
Amps0.038A
Has CameraFalse
IOT EnabledFalse
Lens FinishClear
LensedTrue
Operating PositionUniversal
Power Factor0.9
SDS ClassLED_Lamp
Product TechnologyLED
Incandescent Equivalent40W
Electrical
CCT (Kelvin Temp)2700K
DimmableYes-Dimmable
Hours Rated15000
Beam Angle (degree)360
Color TempWarm White
CRI80+
Dimming TypeReverse Phase or Phase Selectable
Operating Frequency60Hz
Operating Temp-20C (-4F) to +45C (+113F)
Lumens450L
Volts120v
Watts4.5W
Physical
Lamp BaseMedium
FinishClear
ANSI BaseE26
Lamp TypeG25
MOD Lamps3.13
MOL4.38
Additional Info
Warranty2-Years
Rated For Enclosed FixtureTrue
Documents
Compliance
CA RegulationsNon-Compliant - <82 CRI
CA T20 Compliant SubstituteS29878
CA StatusNon-Compliant
CO StatusLawful for sale
FCC CompliantTrue
HI StatusLawful for sale
Location RatingDamp
NV StatusLawful for sale
ROHS CompliantYes
Safety ListingcULus
CA Compliance TextNon-Compliant
VT StatusLawful for sale
WA StatusLawful for sale
DLC ApprovedFalse
Title 20No
T24 CompliantFalse
Packaging
UPC045923295638
Case Cube1.3321
Case Height7.24
Case Length21.54
Case Quantity24
Case UPC10045923295635
Case Weight7.71
Case Width14.76
EA Cube0.0338
EA Height5.33
EA Length3.31
EA Quantity1
EA Weight0.15
EA Width3.31
Inner Cube0.2554
Inner Height6.06
Inner Length10.39
Inner Quantity6
Inner UPC20045923295632
Inner Weight1.55
Inner Width7.01
Pack TypeBox
Web Length4.38
Web Width3.13
