S29676

100W/LED/HID/40K/100-277V/EX39

100 Watt LED HID Replacement; 4000K; Mogul extended base; 100-277 Volt

S29676 100W/LED/HID/40K/100-277V/EX39

S29676

100W/LED/HID/40K/100-277V/EX39

100 Watt LED HID Replacement; 4000K; Mogul extended base; 100-277 Volt

Specifications

General
StatusDiscontinued
SubstituteS39676
Watts100
Incandescent Equivalent500
Fluorescent Equivalent150
HID Equivalent400
Volts100V-277V
ShapeCorncob
BaseMogul Extended
ANSI BaseEX39
FinishClear
CCT (Kelvin)4000
TemperatureCool White
CRI80+
Lumens13000
Beam Spread300
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeCorncob
TechnologyLED
Min Compartment SizeLength 17.3 in. Width 9.25 in. Depth 9.25 in.
Ballasting RequirementsBallastby-pass-Directwireonly100-277V
Electrical
Watts100
Incandescent Equivalent500
Fluorescent Equivalent150
HID Equivalent400
Volts100V-277V
Ballasting RequirementsBallastby-pass-Directwireonly100-277V
Working VoltageAC 90-305V
Operating Frequency50-60 Hz
CCT (Kelvin)4000
TemperatureCool White
CRI80+
Lumens13000
Beam Spread300
DimmableNon-Dimmable
Dimming TypeN/A
Power Factor0.9
Hours Rated50000
Burning PositionUp or Down Operation Only
Surge ProtectionBuilt-in surge protection - 5KV
Thermal ManagementHi-PRO lamps are manufactured with a new Thermal Management circuit design (Temperature Control).I
Operating Temperature-20C (-4F) to a maximum of +40C (+104F)
Physical
MOL9.59
MOD5.88
ShapeCorncob
BaseMogul Extended
ANSI BaseEX39
FinishClear
Lens FinishClear
Housing ColorWhite
Weight (lb.)3.6
Additional Information
Enclosure RatingEnclosed Rated Lamp
IncludesSafety chain
Min Compartment SizeLength 17.3 in. Width 9.25 in. Depth 9.25 in.
Rated For Enclosed FixtureYes
IP RatingIP65
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus
Location RatingWet
Energy StarNo
DLC ApprovedYes
DLC IDPLTRB8U8QX3F
CEC StatusLawful for sale in California
RoHS CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923296765
Each Quantity1
Each Length (in.)7.40
Each Width (in.)7.40
Each Height (in.)11.10
Each Weight (lb.)4.66
Each Cube (CuFt.)0.3411
Pack TypeBox
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923296762
Case Quantity4
Case Length (in.)15.35
Case Width (in.)15.35
Case Height (in.)11.89
Case Weight (lb.)19.84
Case Cube (CuFt.)1.5721
No compatibility links for this item.
×
×
×

Precautions

No precautions available at this time.

×
