» S8716.html

Lights

S8716

100W/LED/HID/50K/277-347VEX39

100W LED HID Replacement; 5000K; Mogul extended base; 277-347V

S8716 100W/LED/HID/50K/277-347VEX39

S8716

100W/LED/HID/50K/277-347VEX39

100W LED HID Replacement; 5000K; Mogul extended base; 277-347V

Specifications

General
StatusDiscontinued
SubstituteS28716
Watts100
Incandescent Equivalent500
Fluorescent Equivalent150
HID Equivalent400
Volts277V-347V
ShapeCorncob
BaseMogul Extended
ANSI BaseEX39
FinishClear
CCT (Kelvin)5000
TemperatureNatural Light
CRI80+
Lumens13300
Beam Spread300
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeCorncob
TechnologyLED
Min Compartment SizeLength 17.3 in. Width 9.25 in. Depth 9.25 in.
Ballasting RequirementsBallast by-pass - Direct wire only 277 - 347V
Electrical
Watts100
Incandescent Equivalent500
Fluorescent Equivalent150
HID Equivalent400
Volts277V-347V
Ballasting RequirementsBallast by-pass - Direct wire only 277 - 347V
Working VoltageAC 250-380V
Operating Frequency50-60 Hz
CCT (Kelvin)5000
TemperatureNatural Light
CRI80+
Lumens13300
Beam Spread300
DimmableNon-Dimmable
Dimming TypeN/A
Power Factor0.9
Hours Rated50000
Burning PositionUniversal
Operating Temperature-20C (-4F) to a maximum of +65C (+149F)
Physical
MOL9.63
MOD5.88
ShapeCorncob
BaseMogul Extended
ANSI BaseEX39
FinishClear
Lens FinishClear
Housing ColorWhite
Additional Information
Enclosure RatingEnclosed Rated Lamp
IncludesSafety chain
Min Compartment SizeLength 17.3 in. Width 9.25 in. Depth 9.25 in.
Rated For Enclosed FixtureYes
IP RatingIP65
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDPLMWC6ZM5OZY;PLPGLEG6HHQ5
CEC StatusLawful for sale in California
RoHS CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923087165
Each Quantity1
Each Length (in.)7.40
Each Width (in.)7.40
Each Height (in.)11.10
Each Weight (lb.)4.66
Each Cube (CuFt.)0.3411
Pack TypeBox
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923087162
Case Quantity4
Case Length (in.)15.40
Case Width (in.)15.40
Case Height (in.)12.20
Case Weight (lb.)20.06
Case Cube (CuFt.)1.6237
No compatibility links for this item.
×
×
×

Precautions

No precautions available at this time.

×
