Lights

S8927

40W/LED/HID/WP/5K/E39/100-277V

40 Watt LED Hi-lumen directional lamp for commercial fixture applications; 5000K; Mogul base; 100-277 Volt

S8927 40W/LED/HID/WP/5K/E39/100-277V

S8927

40W/LED/HID/WP/5K/E39/100-277V

40 Watt LED Hi-lumen directional lamp for commercial fixture applications; 5000K; Mogul base; 100-277 Volt

Specifications

General
StatusDiscontinued
SubstituteS8930
Watts40
HID Equivalent250
Volts100V-277V
ShapeCorncob
BaseMogul
ANSI BaseE39
FinishClear
CCT (Kelvin)5000
TemperatureNatural Light
CRI85
Lumens5600
Beam Spread180
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeCorncob
TechnologyLED
Min Compartment SizeLength 11 in. Width 8 in. Depth 8 in.
Ballasting RequirementsDirectwirevoltagerange100-277V
Electrical
Watts40
HID Equivalent250
Volts100V-277V
Ballasting RequirementsDirectwirevoltagerange100-277V
Operating Frequency50/60 Hz
CCT (Kelvin)5000
TemperatureNatural Light
CRI85
Lumens5600
Beam Spread180
DimmableNon-Dimmable
Dimming TypeN/A
Power Factor0.91
Hours Rated50000
Burning PositionHorizontal Operation
Operating Temperature-29C (-20.2F) to a maximum of +60C (+140F)
Physical
MOL10.63
MOD3.56
ShapeCorncob
BaseMogul
ANSI BaseE39
FinishClear
Lens FinishClear
Housing ColorWhite
Additional Information
Enclosure RatingEnclosed Rated Lamp
Min Compartment SizeLength 11 in. Width 8 in. Depth 8 in.
Rated For Enclosed FixtureYes
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus Classified
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDPYBSPZ5X
CEC StatusLawful for sale in California
RoHS CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923089275
Each Quantity1
Each Length (in.)4.02
Each Width (in.)4.02
Each Height (in.)11.54
Each Weight (lb.)2.12
Each Cube (CuFt.)0.1047
Pack TypeBox
Inner UPC20045923089279
Inner Quantity6
Inner Length (in.)8.63
Inner Width (in.)12.69
Inner Height (in.)12.14
Inner Weight (lb.)13.40
Inner Cube (CuFt.)0.7461
Case UPC10045923089272
Case Quantity12
Case Length (in.)18.04
Case Width (in.)13.28
Case Height (in.)12.73
Case Weight (lb.)28.66
Case Cube (CuFt.)1.7114
