S8929

40W/LED/HID/WP/5K/E26/100-277V

Discontinued - Suggested Replacement: S28929
  • 40 Watt LED Hi-lumen omni-directional lamp for commercial fixture applications
  • 5000K
  • Medium base
  • 100-277 Volt
location_rating^damp^1
rated_for_enclosed_fixture^true^2
hours_rated^50k^2
safety_listing^culus_clas^3
fcc_compliant^true^3
rohs_compliant^y^3
S8929 SpecificationsS8929 InstructionsSA2173 - Hi-Pro LED Wall Pack Lamps PI 9-13-22
Tools
Lighting Layout Analysis For S8929
Create your own analysis for this Part Number
Custom Lighting Layout Analysis
Request a lighting layout
Description
Description
40 Watt LED Hi-lumen omni-directional lamp for commercial fixture applications; 5000K; Medium base; 100-277 Volt
Products Specs
General
CompanySATCO
Lamp FilamentLED
Fixture TypeCorncob
StatusObsolete
Most Current GenerationS28929
Surge ProtectionBuilt-in surge protection - 4KV
CCT SelectableFalse
Wattage SelectableFalse
Finish FamilyNo Finish
Amps0.400-0.144A
Has CameraFalse
IOT EnabledFalse
Lens FinishClear
LensedTrue
Minimum Compartment SizeLength: 11 in. Width: 8 in. Depth: 8 in.
Operating PositionHorizontal
Power Factor>0.9
SDS ClassLED_Lamp
Product TechnologyLED
Incandescent Equivalent125W
Electrical
CCT (Kelvin Temp)5000K
DimmableNon-Dimmable
Hours Rated50000
Beam Angle (degree)180
Color TempNatural Light
CRI80+
Operating Frequency50/60Hz
Operating Temp-30C (-22F) to +45C (+113F)
HID Equivalent175W
Lumens6000L
Volts120V-277V
Watts40W
Physical
Lamp BaseMedium
FinishClear
Housing ColorWhite
ANSI BaseE26
Lamp TypeCorncob
MOD Lamps3.13
MOL7.81
Additional Info
Warranty5-Years
Installation NotesNot for use in vapor tight fixtures.
Rated For Enclosed FixtureTrue
Documents
Compliance
CA RegulationsExempt - >2600 Lumens
CA StatusLawful for sale in California
CO StatusLawful for sale
FCC CompliantTrue
HI StatusLawful for sale
IP RatingIP64
Location RatingDamp
NV StatusLawful for sale
ROHS CompliantYes
Safety ListingcULus - Certified, cULus - Classified
CA Compliance TextLawful for sale
VT StatusLawful for sale
WA StatusLawful for sale
DLC ApprovedFalse
Title 20Exempt
T24 CompliantFalse
Packaging
UPC045923089299
Case Cube1.568
Case Height11.54
Case Length17.64
Case Quantity12
Case UPC10045923089296
Case Weight26.46
Case Width13.31
EA Cube0.095
EA Height10.16
EA Length4.02
EA Quantity1
EA Weight1.98
EA Width4.02
Inner Cube0.0
Inner Height0.0
Inner Length0.0
Inner Quantity0
Inner Weight0.0
Inner Width0.0
Pack TypeBox
Web Length7.81
Web Width3.13
