Lights

S8930

40W/LED/HID/WP/5K/E39/100-277V

40 Watt LED Hi-lumen omni-directional lamp for commercial fixture applications; 5000K; Mogul base; 100-277 Volt

S8930 40W/LED/HID/WP/5K/E39/100-277V

S8930

40W/LED/HID/WP/5K/E39/100-277V

40 Watt LED Hi-lumen omni-directional lamp for commercial fixture applications; 5000K; Mogul base; 100-277 Volt

Specifications

General
StatusActive
Watts40
HID Equivalent175
Volts100V-277V
ShapeCorncob
BaseMogul
ANSI BaseE39
FinishClear
CCT (Kelvin)5000
TemperatureNatural Light
CRI80+
Lumens6000
Beam Spread180
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeCorncob
TechnologyLED
Min Compartment SizeLength 11 in. Width 8 in. Depth 8 in.
Electrical
Watts40
HID Equivalent175
Volts100V-277V
Operating Frequency50/60 Hz
CCT (Kelvin)5000
TemperatureNatural Light
CRI80+
Lumens6000
Beam Spread180
DimmableNon-Dimmable
Power Factor>0.9
Hours Rated50000
Burning PositionHorizontal Operation
Surge ProtectionBuilt-in surge protection - 4KV
Operating Temperature-30C (-22F) to a maximum of +45C (+113F)
Physical
MOL8.5
MOD3.13
ShapeCorncob
BaseMogul
ANSI BaseE39
FinishClear
Lens FinishClear
Housing ColorWhite
Additional Information
Enclosure RatingEnclosed Rated Lamp
Min Compartment SizeLength 11 in. Width 8 in. Depth 8 in.
Rated For Enclosed FixtureYes
IP RatingIP64
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus Classified
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDPL2YDXWVA1LX
CEC StatusLawful for sale in California
RoHS CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923089305
Each Quantity1
Each Length (in.)4.02
Each Width (in.)4.02
Each Height (in.)10.16
Each Weight (lb.)1.98
Each Cube (CuFt.)0.0921
Pack TypeBox
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923089302
Case Quantity12
Case Length (in.)17.64
Case Width (in.)13.31
Case Height (in.)11.54
Case Weight (lb.)26.46
Case Cube (CuFt.)1.5205
