S8937

110W/LED/HID/SB/3K/E39/100-277

110W LED Hi-lumen shoe box style lamp for commercial fixture applications; 3000K; Mogul base; 100-277V

Lights

S8937

110W/LED/HID/SB/3K/E39/100-277

110W LED Hi-lumen shoe box style lamp for commercial fixture applications; 3000K; Mogul base; 100-277V

Specifications

General
StatusActive
Watts110
HID Equivalent400
Volts100V-277V
ShapeCorncob
BaseMogul
ANSI BaseE39
FinishArray
CCT (Kelvin)3000
TemperatureWarm White
CRI85
Lumens14000
Beam Spread180
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeCorncob
TechnologyLED
Min Compartment SizeLength 11.3 in. Width 11 in. Depth 11 in.
Ballasting RequirementsDirect wire voltage range 100-277V
Electrical
Watts110
HID Equivalent400
Volts100V-277V
Ballasting RequirementsDirect wire voltage range 100-277V
Operating Frequency50/60 Hz
CCT (Kelvin)3000
TemperatureWarm White
CRI85
Lumens14000
Beam Spread180
DimmableNon-Dimmable
Dimmable Down ToN/A
Dimming TypeN/A
Power Factor0.91
Hours Rated50000
Burning PositionHorizontal Operation
Operating Temperature-29C (-20F) to a maximum of +60C (+140F)
Physical
MOL11.06
MOD4.38
ShapeCorncob
BaseMogul
ANSI BaseE39
FinishArray
Housing ColorWhite
Additional Information
Enclosure RatingEnclosed Rated Lamp
Min Compartment SizeLength 11.3 in. Width 11 in. Depth 11 in.
IP RatingIP64
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus Classified
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDP94BH92A
CEC StatusLawful for sale in California
RoHS CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923089374
Each Quantity1
Each Length (in.)12.69
Each Width (in.)5.71
Each Height (in.)6.30
Each Weight (lb.)4.72
Each Cube (CuFt.)0.26
Pack TypeBox
Inner UPC00000000000000
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.00
Case UPC10045923089371
Case Quantity4
Case Length (in.)13.28
Case Width (in.)12.02
Case Height (in.)13.20
Case Weight (lb.)20.24
Case Cube (CuFt.)1.18
×

Dimmer Compatibility

×

Precautions

No precautions available at this time.
