Lights

S8938

110W/LED/HID/SB/5K/E39/100-277

110 Watt LED Hi-lumen shoe box style lamp for commercial fixture applications; 5000K; Mogul base; 100-277 Volt

S8938 110W/LED/HID/SB/5K/E39/100-277

S8938

110W/LED/HID/SB/5K/E39/100-277

110 Watt LED Hi-lumen shoe box style lamp for commercial fixture applications; 5000K; Mogul base; 100-277 Volt

Specifications

General
StatusActive
Watts110
HID Equivalent400
Volts100V-277V
ShapeCorncob
BaseMogul
ANSI BaseE39
FinishClear
CCT (Kelvin)5000
TemperatureNatural Light
CRI80+
Lumens14000
Beam Spread180
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeCorncob
TechnologyLED
Min Compartment SizeLength 11.3 in. Width 11 in. Depth 11 in.
Ballasting RequirementsDirectwirevoltagerange100-277V
Electrical
Watts110
HID Equivalent400
Volts100V-277V
Ballasting RequirementsDirectwirevoltagerange100-277V
Operating Frequency50/60 Hz
CCT (Kelvin)5000
TemperatureNatural Light
CRI80+
Lumens14000
Beam Spread180
DimmableNon-Dimmable
Dimming TypeN/A
Power Factor>0.9
Hours Rated50000
Burning PositionHorizontal Operation
Operating Temperature-30C (-22F) to a maximum of +45C (+113F)
Physical
MOL11.06
MOD4.38
ShapeCorncob
BaseMogul
ANSI BaseE39
FinishClear
Lens FinishClear
Housing ColorWhite
Additional Information
Enclosure RatingEnclosed Rated Lamp
Min Compartment SizeLength 11.3 in. Width 11 in. Depth 11 in.
Rated For Enclosed FixtureYes
IP RatingIP64
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus Classified
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDPKF8DJT8
CEC StatusLawful for sale in California
RoHS CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923089381
Each Quantity1
Each Length (in.)12.69
Each Width (in.)5.71
Each Height (in.)6.30
Each Weight (lb.)4.72
Each Cube (CuFt.)0.2562
Pack TypeBox
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923089388
Case Quantity4
Case Length (in.)13.28
Case Width (in.)12.02
Case Height (in.)13.20
Case Weight (lb.)20.24
Case Cube (CuFt.)1.1824
No compatibility links for this item.
×
×
×

Precautions

No precautions available at this time.

×
