| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type B |
| Ballasting Requirements | Ballast Bypass- Direct wire only 100V-277V |
| CA Regulations | Exempt - Base Not Regulated |
| Lamp Filament | LED |
| Fixture Type | Corncob |
| Status | Discontinued |
| Surge Protection | Built-in surge protection |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | No Finish |
| Additional Info | Built-in motion sensor - Detection area 32-feet; 30 second turn off |
| Amps | 0.630-0.227A |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | Clear |
| Lensed | True |
| Minimum Compartment Size | Length: 11 in. Width: 8 in. Depth: 8 in. |
| Operating Position | Universal |
| Photo Cell | Has Motion Sensor |
| Power Factor | >0.9 |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Incandescent Equivalent | 300W |
| CCT (Kelvin Temp) | 5000K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 300 |
| Color Temp | Natural Light |
| CRI | 80+ |
| Operating Temp | -30C (-22F) to +60C (+140F) |
| HID Equivalent | 250W |
| Lumens | 7875L |
| Volts | 120V-277V |
| Watts | 63W |
| Lamp Base | Mogul |
|---|---|
| Finish | Clear |
| Housing Color | White |
| ANSI Base | E39 |
| Lamp Type | Corncob |
| MOD Lamps | 3.38 |
| MOL | 10.88 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | True |
| CA Status | Lawful for sale in California |
|---|---|
| CO Status | Lawful for sale |
| FCC Compliant | True |
| HI Status | Lawful for sale |
| IP Rating | IP42 |
| Location Rating | Damp |
| NV Status | Lawful for sale |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Classified |
| CA Compliance Text | Lawful for sale |
| VT Status | Lawful for sale |
| WA Status | Lawful for sale |
| DLC Approved | False |
| Title 20 | Exempt |
| T24 Compliant | False |
| UPC | 045923089893 |
|---|---|
| Case Cube | 1.5871 |
| Case Height | 13.58 |
| Case Length | 16.54 |
| Case Quantity | 12 |
| Case UPC | 10045923089890 |
| Case Weight | 28.18 |
| Case Width | 12.21 |
| EA Cube | 0.0949 |
| EA Height | 12.24 |
| EA Length | 3.66 |
| EA Quantity | 1 |
| EA Weight | 2.07 |
| EA Width | 3.66 |
| Inner Cube | 0.6784 |
| Inner Height | 12.83 |
| Inner Length | 11.61 |
| Inner Quantity | 6 |
| Inner UPC | 20045923089897 |
| Inner Weight | 13.49 |
| Inner Width | 7.87 |
| Pack Type | Box |
| Web Length | 10.88 |
| Web Width | 3.38 |
