| Company | SATCO |
|---|---|
| Lamp Filament | LED |
| Fixture Type | Linear |
| Status | Discontinued |
| Most Current Generation | S49977R1 |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | White |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | Gloss White |
| Lensed | True |
| Nominal Length | 48.0 |
| Operating Position | Universal |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Fluor Equiv | 25W-32W |
| Incandescent Equivalent | 100W |
| CCT (Kelvin Temp) | 4000K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 230 |
| Color Temp | Cool White |
| CRI | 80+ |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Lumens | 2200L |
| Watts | 17W |
| Lamp Base | Medium Bi Pin |
|---|---|
| Finish | Gloss White |
| ANSI Base | G13 |
| Lamp Type | T8 |
| MOD Lamps | 1.0 |
| MOL | 48.0 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| CA Regulations | Exempt - Base Not Regulated |
|---|---|
| CA Status | Lawful for sale in California |
| CO Status | Lawful for sale |
| FCC Compliant | True |
| HI Status | Lawful for sale |
| Location Rating | Damp |
| NV Status | Lawful for sale |
| ROHS Compliant | Yes |
| Safety Listing | cULus |
| CA Compliance Text | Lawful for sale |
| VT Status | Lawful for sale |
| WA Status | Lawful for sale |
| DLC Approved | False |
| Title 20 | Exempt |
| T24 Compliant | False |
| UPC | 045923092770 |
|---|---|
| Case Cube | 2.0557 |
| Case Height | 8.66 |
| Case Length | 49.6 |
| Case Quantity | 10 |
| Case UPC | 10045923092777 |
| Case Weight | 4.4 |
| Case Width | 8.27 |
| EA Cube | 0.0289 |
| EA Height | 1.02 |
| EA Length | 48.0 |
| EA Quantity | 1 |
| EA Weight | 0.44 |
| EA Width | 1.02 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Egg Crate |
| Web Length | 48.0 |
| Web Width | 1.0 |
