SKU S9391 - Image 1
SKU S9391 - Image 2
S9391

22W/LED/HID/5000K/100-277V E26

Discontinued - Suggested Replacement: S49391
  • 22 Watt - LED HID Replacement
  • 5000K
  • Medium base
  • 100-277 Volt
location_rating^damp^1
lamp_ballast_type_ab^type_b^1
ip_rating^IP65^1
rated_for_enclosed_fixture^true^2
hours_rated^50k^2
safety_listing^culus_list^3
fcc_compliant^true^3
rohs_compliant^y^3
S9391 SpecificationsSA1767 Hi-Pro LED Lamps V2 PI Sheet 4 17
Tools
Lighting Layout Analysis For S9391
Create your own analysis for this Part Number
Custom Lighting Layout Analysis
Request a lighting layout
Description
Description
22 Watt - LED HID Replacement; 5000K; Medium base; 100-277 Volt
Products Specs
General
CompanySATCO
Lamp Ballast Type ABType B
Ballasting RequirementsBallast Bypass- Direct wire only 100V-277V
Lamp FilamentLED
Fixture TypeCorncob
StatusDiscontinued
Most Current GenerationS49391
Working VoltageAC 90-305V
CCT SelectableFalse
Wattage SelectableFalse
Finish FamilyNo Finish
Amps0.220-0.079A
Has CameraFalse
IOT EnabledFalse
Lens FinishClear
LensedTrue
Minimum Compartment SizeLength: 8.5 in. Width: 6 in. Depth: 6 in.
Operating PositionUniversal
Power Factor>.9
SDS ClassLED_Lamp
Product TechnologyLED
Fluor Equiv40W
Incandescent Equivalent150W
Electrical
CCT (Kelvin Temp)5000K
DimmableNon-Dimmable
Hours Rated50000
Beam Angle (degree)300
Color TempNatural Light
CRI80+
Operating Frequency50/60Hz
Operating Temp-20C (-4F) to +65C (+149F)
HID Equivalent100W
Lumens2950L
Volts120V-277V
Watts22W
Physical
Lamp BaseMedium
FinishClear
Housing ColorWhiteGrey
ANSI BaseE26
Lamp TypeCorncob
MOD Lamps2.75
MOL7.69
Additional Info
Warranty5-Years
Installation NotesNot for use in vapor tight fixtures.
Rated For Enclosed FixtureTrue
Documents
Compliance
CA RegulationsExempt - >2600 Lumens
CA StatusLawful for sale in California
CO StatusLawful for sale
FCC CompliantTrue
HI StatusLawful for sale
IP RatingIP65
Location RatingDamp
NV StatusLawful for sale
ROHS CompliantYes
Safety ListingcULus - Certified, cULus - Listed
CA Compliance TextLawful for sale
VT StatusLawful for sale
WA StatusLawful for sale
DLC ApprovedFalse
Title 20Exempt
T24 CompliantFalse
Packaging
UPC045923093913
Case Cube3.9568
Case Height20.08
Case Length22.64
Case Quantity48
Case UPC10045923093910
Case Weight62.39
Case Width15.04
EA Cube0.0569
EA Height8.5
EA Length3.4
EA Quantity1
EA Weight1.17
EA Width3.4
Inner Cube0.8452
Inner Height9.29
Inner Length14.37
Inner Quantity12
Inner UPC20045923093917
Inner Weight14.99
Inner Width10.94
Pack TypeBox
Web Length7.69
Web Width2.75
