S9394

54W/LED/HID/5000K/100-277V EX3

54 Watt LED HID Replacement; 5000K; Mogul extended base; 100-277 Volt

S9394 54W/LED/HID/5000K/100-277V EX3

S9394

54W/LED/HID/5000K/100-277V EX3

54 Watt LED HID Replacement; 5000K; Mogul extended base; 100-277 Volt

Specifications

General
StatusDiscontinued
Watts54
Incandescent Equivalent300
Fluorescent Equivalent85
HID Equivalent250
Volts100V-277V
ShapeCorncob
BaseMogul Extended
ANSI BaseEX39
CCT (Kelvin)5000
TemperatureNatural Light
CRI80+
Lumens7200
Beam Spread300
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeCorncob
TechnologyLED
Min Compartment SizeLength 17.3 in. Width 9.25 in. Depth 9.25 in.
Ballasting RequirementsBallastby-pass-Directwireonly100-277V
Electrical
Watts54
Incandescent Equivalent300
Fluorescent Equivalent85
HID Equivalent250
Volts100V-277V
Ballasting RequirementsBallastby-pass-Directwireonly100-277V
Working VoltageAC 90-305V
Operating Frequency50/60 Hz
CCT (Kelvin)5000
TemperatureNatural Light
CRI80+
Lumens7200
Beam Spread300
DimmableNon-Dimmable
Dimming TypeN/A
Power Factor0.91
Hours Rated50000
Burning PositionUniversal
Operating Temperature-20C (-4F) to a maximum of +65C (+149F)
Physical
MOL10.75
MOD3.69
ShapeCorncob
BaseMogul Extended
ANSI BaseEX39
Housing ColorWhite
Additional Information
Enclosure RatingEnclosed Rated Lamp
Min Compartment SizeLength 17.3 in. Width 9.25 in. Depth 9.25 in.
Rated For Enclosed FixtureYes
IP RatingIP65
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDP7RMM9YA;PMM9NX2Z
CEC StatusLawful for sale in California
RoHS CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923093944
Each Quantity1
Each Length (in.)4.96
Each Width (in.)4.96
Each Height (in.)11.60
Each Weight (lb.)2.62
Each Cube (CuFt.)0.1601
Pack TypeBox
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923093941
Case Quantity12
Case Length (in.)15.75
Case Width (in.)10.63
Case Height (in.)24.02
Case Weight (lb.)33.95
Case Cube (CuFt.)2.2567
