S9545

LED 3W JC/G6.35 12V 5000K 300L

  • 3W
  • JC LED
  • 5000K
  • G6.35 base
  • 12 Volt AC/DC
location_rating^damp^1
dimmable^dimmable^2
rated_for_enclosed_fixture^true^2
hours_rated^25k^2
safety_listing^cetlus^3
fcc_compliant^true^3
rohs_compliant^y^3
S9545 SpecificationsSA2229 Silicon LED G and BA Bases PI Sheets 11 17
Tools
Lighting Layout Analysis For S9545
Create your own analysis for this Part Number
Custom Lighting Layout Analysis
Request a lighting layout
Description
Description
3W; JC LED; 5000K; G6.35 base; 12 Volt AC/DC
Products Specs
General
CompanySATCO
Lamp FilamentLED
MaterialSilicon
Fixture TypeMiniature
StatusDiscontinued
Most Current GenerationS12317
CCT SelectableFalse
Wattage SelectableFalse
Finish FamilyNo Finish
Amps0.250A
Has CameraFalse
IOT EnabledFalse
Lens FinishClear
LensedTrue
Operating PositionUniversal
SDS ClassLED_Lamp
Product TechnologyLED
Incandescent Equivalent25W
Electrical
CCT (Kelvin Temp)5000K
DimmableYes-Dimmable
Hours Rated25000
Beam Angle (degree)360
Color TempNatural Light
CRI80+
Dimming TypeReverse Phase or Phase Selectable
Operating Temp-20C (-4F) to +45C (+113F)
HID Equivalent35W
Lumens300L
Volts12V
Watts3W
Physical
Lamp BaseBi Pin G6.35
FinishClear
ANSI BaseG6.35
Lamp TypeT4
MOD Lamps0.5
MOL1.63
Additional Info
Warranty5-Years
Installation NotesNot for use in vapor tight fixtures.
Rated For Enclosed FixtureTrue
Documents
Compliance
CA RegulationsExempt - Base Not Regulated
CA StatusLawful for sale in California
CO StatusLawful for sale
FCC CompliantTrue
HI StatusLawful for sale
Location RatingDamp
NV StatusLawful for sale
ROHS CompliantYes
Safety ListingcETLus
CA Compliance TextLawful for sale
VT StatusLawful for sale
WA StatusLawful for sale
DLC ApprovedFalse
Title 20Exempt
T24 CompliantFalse
Packaging
UPC045923095450
Case Cube0.1911
Case Height4.75
Case Length17.38
Case Quantity200
Case UPC10045923095457
Case Weight4.99
Case Width4.0
EA Cube0.0006
EA Height1.75
EA Length0.63
EA Quantity1
EA Weight0.02
EA Width0.88
Inner Cube0.0142
Inner Height2.0
Inner Length3.63
Inner Quantity20
Inner UPC20045923095454
Inner Weight0.46
Inner Width3.38
Pack TypeBox
Web Length1.63
Web Width0.5
