10.5A19/OMNI/LED/27K/90/GU24 - S9613
S9613

10.5A19/OMNI/LED/27K/90/GU24

Discontinued - Suggested Replacement: S9707
  • 10.5 watt
  • A19 LED
  • 2700K
  • GU24 base
  • 315' beam spread
  • 120 volts
location_rating^damp^1
title_24^y^1
cri^90+^2
dimmable^dimmable^2
rated_for_enclosed_fixture^true^2
hours_rated^25k^2
volts^120v^2
fcc_compliant^true^3
rohs_compliant^y^3
S9613 Specifications
Description
Description
10.5 watt; A19 LED; 2700K; GU24 base; 315' beam spread; 120 volts
Products Specs
General
CompanySATCO
Dimmable TextForward Phase or Reverse Phase
Lamp FilamentLED
Fixture TypeType A
StatusObsolete
CCT SelectableNo
Wattage SelectableNo
Finish FamilyWhite
Amps0.088A
Has CameraNo
IOT EnabledNo
Lens FinishFrost
LensedYes
Operating PositionUniversal
Power Factor0.9
SDS ClassLED_Lamp
Product TechnologyLED
Incandescent Equivalent60W
Electrical
CCT (Kelvin Temp)2700K
DimmableYes-Dimmable
Hours Rated25000
Beam Angle (degree)315
Color TempWarm White
CRI90+
Dimming Type120V only, Phase cut
Operating Temp-20C (-4F) to +45C (+113F)
Lumens800L
Volts120v
Watts10.5W
Physical
Lamp BaseBi Pin GU24
FinishFrost
Housing ColorWhite
ANSI BaseGU24
Lamp TypeA19
MOD Lamps2.38
MOL4.5
Additional Info
Warranty5-Years
Rated For Enclosed FixtureYes
Documents
Compliance
FCC CompliantYes
Location RatingDamp
ROHS CompliantYes
Safety ListingcULus
California BanCalifornia T24 Listed
DLC ApprovedNo
Title 20No
T24 CompliantYes
Packaging
UPC045923096136
Case Cube0.9212
Case Height12.68
Case Length13.98
Case Quantity24
Case UPC10045923096133
Case Weight8.93
Case Width8.98
EA Cube0.0242
EA Height5.24
EA Length3.07
EA Quantity1
EA Weight0.32
EA Width2.6
Inner Cube0.1821
Inner Height5.79
Inner Length8.31
Inner Quantity6
Inner UPC20045923096130
Inner Weight2.09
Inner Width6.54
Pack TypeBox
Web Length4.5
Web Width2.38
