S9631

6.5R20/LED/3000K/525L/120V

  • 6.5 Watt
  • LED R20
  • 3000K
  • 107 deg. Beam Angle
  • Medium base
  • 120 Volt
  • Dimmable
location_rating^damp^1
dimmable^dimmable^2
rated_for_enclosed_fixture^true^2
hours_rated^25k^2
volts^120v^2
safety_listing^culus_list^3
fcc_compliant^true^3
rohs_compliant^y^3
S9631 SpecificationsS9631 LFLSA2629 LED BR20 Reflector PI 10 24
Tools
Lighting Layout Analysis For S9631
Create your own analysis for this Part Number
Custom Lighting Layout Analysis
Request a lighting layout
Description
Description
6.5 Watt; LED R20; 3000K; 107 deg. Beam Angle; Medium base; 120 Volt; Dimmable
Products Specs
General
CompanySATCO
Candle Power180.0
Center Beam Candle Power180
Lamp FilamentLED
Fixture TypeReflector
StatusActive
StyleContemporary
CCT SelectableFalse
Wattage SelectableFalse
Finish FamilyWhite
Amps0.054A
Has CameraFalse
IOT EnabledFalse
Lens FinishFrost
LensedTrue
Operating PositionUniversal
Power Factor0.92
SDS ClassLED_Lamp
Indoor OutdoorIndoor
Product TechnologyLED
Incandescent Equivalent45W
Electrical
CCT (Kelvin Temp)3000K
DimmableYes-Dimmable
Hours Rated25000
Beam Angle (degree)107
Color TempWarm White
CRI80+
Dimming TypeForward Phase or Reverse Phase or Phase Selectable
Operating Frequency60Hz
Operating Temp-25C (-13F) to +45C (+113F)
Lumens525L
Volts120v
Watts6.5W
Physical
Lamp BaseMedium
FinishFrost
Housing ColorGray
ANSI BaseE26
Lamp TypeR20
MOD Lamps2.5
MOL3.94
Additional Info
Warranty5-Years
Rated For Enclosed FixtureTrue
Documents
Compliance
CA RegulationsNon-Compliant - <82 CRI
CA T20 Compliant SubstituteS28577
CA StatusNon-Compliant
CO StatusLawful for sale
FCC CompliantTrue
HI StatusLawful for sale
Location RatingDamp
NV StatusLawful for sale
ROHS CompliantYes
Safety ListingcULus - Certified, cULus - Listed
CA Compliance TextNon-Compliant
VT StatusLawful for sale
WA StatusLawful for sale
DLC ApprovedFalse
Title 20No
T24 CompliantFalse
Packaging
UPC045923096310
Case Cube0.6531
Case Height10.43
Case Length12.05
Case Quantity24
Case UPC10045923096317
Case Weight5.6
Case Width8.98
EA Cube0.0166
EA Height4.25
EA Length2.6
EA Quantity1
EA Weight0.17
EA Width2.6
Inner Cube0.125
Inner Height4.65
Inner Length8.31
Inner Quantity6
Inner UPC20045923096314
Inner Weight1.28
Inner Width5.59
Pack TypeBox
Web Length3.94
Web Width2.5
