| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type B |
| Ballasting Requirements | Ballast Bypass- Direct wire only 100V-277V |
| Lamp Filament | LED |
| Fixture Type | Corncob |
| Status | Obsolete |
| Working Voltage | AC 90-305V |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | No Finish |
| Amps | 0.220-0.079A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | Clear |
| Lensed | Yes |
| Minimum Compartment Size | Length: 8.5 in. Width: 6 in. Depth: 6 in. |
| Operating Position | Universal |
| Power Factor | >0.9 |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Fluor Equiv | 40W |
| Incandescent Equivalent | 150W |
| CCT (Kelvin Temp) | 2700K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 300 |
| Color Temp | Warm White |
| CRI | 80+ |
| Operating Frequency | 50/60Hz |
| Operating Temp | -20C (-4F) to +65C (+149F) |
| HID Equivalent | 100W |
| Lumens | 2680L |
| Volts | 120V-277V |
| Watts | 22W |
| Lamp Base | Medium |
|---|---|
| Finish | Clear |
| Housing Color | WhiteGrey |
| ANSI Base | E26 |
| Lamp Type | Corncob |
| MOD Lamps | 2.75 |
| MOL | 7.69 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | Yes |
| FCC Compliant | Yes |
|---|---|
| IP Rating | IP65 |
| Location Rating | Damp |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Listed |
| California Ban | Lawful for sale |
| DLC Approved | No |
| Title 20 | Exempt |
| T24 Compliant | No |
| UPC | 045923096716 |
|---|---|
| Case Cube | 3.8142 |
| Case Height | 20.9 |
| Case Length | 21.6 |
| Case Quantity | 48 |
| Case UPC | 10045923096713 |
| Case Weight | 51.4 |
| Case Width | 14.6 |
| EA Cube | 0.0354 |
| EA Height | 8.03 |
| EA Length | 2.76 |
| EA Quantity | 1 |
| EA Weight | 0.96 |
| EA Width | 2.76 |
| Inner Cube | 0.9143 |
| Inner Height | 9.84 |
| Inner Length | 14.57 |
| Inner Quantity | 12 |
| Inner UPC | 20045923096710 |
| Inner Weight | 15.19 |
| Inner Width | 11.02 |
| Pack Type | Box |
| Web Length | 7.69 |
| Web Width | 2.75 |
