Discontinued – Suggested Replacement: S39799
S9799 60W/LED/HID/MB/2700K/100-277V

S9799

60W/LED/HID/MB/2700K/100-277V

60 Watt - LED HID Replacement; 2700K; Mogul extended base; Adjustable beam angle; 100-277 Volt


Lights

S9799

60W/LED/HID/MB/2700K/100-277V

60 Watt - LED HID Replacement; 2700K; Mogul extended base; Adjustable beam angle; 100-277 Volt

Specifications

General
StatusDiscontinued
SubstituteS39799
Watts60W
Incandescent Equivalent500W
Fluorescent Equivalent85W
HID Equivalent250W
Volts100V-277V
ShapeCorncob
BaseMogul Extended
ANSI BaseEX39
FinishClear
CCT (Kelvin)2700K
TemperatureWarm White
CRI83
Lumens7320L
Beam Spread360
DimmableNon-Dimmable
Hours Rated50000
Product CategoryCorncob
Lamp TypeCorncob
TechnologyLED
Min Compartment SizeLength: 8.27 in. Width: 9.25 in. Depth: 9.25 in.
Ballasting RequirementsBallast Bypass
Electrical
Watts60W
Incandescent Equivalent500W
Fluorescent Equivalent85W
HID Equivalent250W
Volts100V-277V
Ballasting RequirementsBallast Bypass
Working VoltageAC 90-305V
Operating Frequency50-60Hz
CCT (Kelvin)2700K
TemperatureWarm White
CRI83
Lumens7320L
Beam Spread360
DimmableNon-Dimmable
Power Factor0.9
Hours Rated50000
Operating PositionUniversal
Operating Temperature-20C (-4F) to +65C (+149F)
Physical
MOL8.56
MOD3.81
ShapeCorncob
BaseMogul Extended
ANSI BaseEX39
FinishClear
Lens FinishClear
Housing ColorWhite
Additional Information
Additional InfoWidth 360 deg 3.8 in.; Width 270 deg 8.2 in.; Width 180 deg 9.3 in.
Min Compartment SizeLength: 8.27 in. Width: 9.25 in. Depth: 9.25 in.
Rated For Enclosed FixtureYes
IP RatingIP65
Installation NotesArms fully open diameter is 10.88 inches
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus
Location RatingDamp
Energy StarNo
DLC ApprovedNo
CA T20 / T24 RationaleExempt - Base Not Regulated
RoHS CompliantYes
FCC CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923097997
Each Quantity1
Each Length (in.)5.90
Each Width (in.)5.90
Each Height (in.)10.20
Each Weight (lb.)2.66
Each Cube (CuFt.)0.2055
Pack TypeBox
Inner UPC20045923097991
Inner Quantity6
Inner Length (in.)15.35
Inner Width (in.)9.45
Inner Height (in.)10.24
Inner Weight (lb.)16.38
Inner Cube (CuFt.)0.8596
Case UPC10045923097994
Case Quantity12
Case Length (in.)21.46
Case Width (in.)16.14
Case Height (in.)10.43
Case Weight (lb.)34.45
Case Cube (CuFt.)2.0906
