| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type B |
| Ballasting Requirements | Ballast Bypass |
| Lamp Filament | LED |
| Fixture Type | Linear |
| Status | Discontinued |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | White |
| Amps | 0.358-0.155A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | Gloss White |
| Lensed | Yes |
| Minimum Compartment Size | Length: 96.063 in. Width: 10.630 in. Heigth: 2.756 in. |
| Nominal Length | 96.0 |
| Operating Position | Universal |
| Power Factor | 0.9 |
| SDS Class | LED_Lamp |
| Shatter Proof Type | Yes |
| Product Technology | LED |
| Fluor Equiv | 54W/59W |
| Incandescent Equivalent | 125W |
| CCT (Kelvin Temp) | 3500K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 210 |
| Color Temp | Neutral White |
| CRI | 80+ |
| Operating Frequency | 50/60Hz |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Lumens | 5300L |
| Volts | 120V-277V |
| Watts | 43W |
| Lamp Base | Single Pin |
|---|---|
| Finish | Gloss White |
| ANSI Base | Fa8 |
| Lamp Type | T8 |
| MOD Lamps | 1.0 |
| MOL | 96.0 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | Yes |
| FCC Compliant | Yes |
|---|---|
| Location Rating | Damp |
| NSF Approved | Yes |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Classified |
| California Ban | Lawful for sale |
| DLC Approved | No |
| Title 20 | Exempt |
| T24 Compliant | No |
| UPC | 045923099175 |
|---|---|
| Case Cube | 1.8417 |
| Case Height | 4.33 |
| Case Length | 95.7 |
| Case Quantity | 10 |
| Case UPC | 10045923099172 |
| Case Weight | 13.67 |
| Case Width | 7.68 |
| EA Cube | 0.0521 |
| EA Height | 0.98 |
| EA Length | 93.78 |
| EA Quantity | 1 |
| EA Weight | 0.26 |
| EA Width | 0.98 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Egg Crate |
| Web Length | 96.0 |
| Web Width | 1.0 |
