Discontinued – Suggested Replacement: S29918
S9918 43T8/LED/96-840/BP 120-277V

S9918

43T8/LED/96-840/BP 120-277V

43 Watt T8 LED; Single pin base; 4000K; 50000 Average rated hours; 5500 Lumens; Type B; Ballast Bypass; Double Ended Wiring


Lights

S9918

43T8/LED/96-840/BP 120-277V

43 Watt T8 LED; Single pin base; 4000K; 50000 Average rated hours; 5500 Lumens; Type B; Ballast Bypass; Double Ended Wiring

Specifications

General
StatusDiscontinued
SubstituteS29918
Watts43W
Incandescent Equivalent125W
Fluorescent Equivalent54W/59W
Volts120V-277V
Ballast TypeType B
ShapeT8
BaseSingle Pin
ANSI BaseFa8
Nominal Length96
FinishGloss White
CCT (Kelvin)4000K
TemperatureCool White
CRI82
Lumens5500L
Beam Spread210
DimmableNon-Dimmable
Hours Rated50000
Product CategoryLinear
Lamp TypeLinear
TechnologyLED
Electrical
Watts43W
Incandescent Equivalent125W
Fluorescent Equivalent54W/59W
Volts120V-277V
Ballasting RequirementsBallast Bypass
Ballast TypeType B
Operating Frequency50/60Hz
CCT (Kelvin)4000K
TemperatureCool White
CRI82
Lumens5500L
Beam Spread210
DimmableNon-Dimmable
Power Factor0.9
Hours Rated50000
Operating Temperature-20C (-4F) to +45C (+113F)
Physical
MOL96
MOD1
Nominal Length96
ShapeT8
BaseSingle Pin
ANSI BaseFa8
FinishGloss White
Lens FinishGloss White
Additional Information
Shatter-Proof TypeYes
Rated For Enclosed FixtureYes
Warranty5 Year Limited - T8 LED Bulbs - Ballast Bypass
Compliance
Safety ListingcULus - Classified; cULus - Certified
Location RatingDamp
Energy StarNo
DLC ApprovedNo
CA T20 / T24 RationaleExempt - Base Not Regulated
RoHS CompliantYes
FCC CompliantYes
NSF ApprovedYes
SDS SheetLED Lamp
Packaging
Each UPC045923099182
Each Quantity1
Each Length (in.)93.78
Each Width (in.)0.98
Each Height (in.)0.98
Each Weight (lb.)0.26
Each Cube (CuFt.)0.0521
Pack TypeEgg Crate
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923099189
Case Quantity10
Case Length (in.)95.70
Case Width (in.)7.68
Case Height (in.)4.33
Case Weight (lb.)13.67
Case Cube (CuFt.)1.8417
No compatibility links for this item.
×
×
×

Precautions

No precautions available at this time.

×
