S9918

43T8/LED/96-840/BP 120-277V

43 Watt T8 LED; Single pin base; 4000K; 50000 Average rated hours; 5500 Lumens; Type B; Ballast Bypass; Double Ended Wiring

S9918 43T8/LED/96-840/BP 120-277V

S9918

43T8/LED/96-840/BP 120-277V

43 Watt T8 LED; Single pin base; 4000K; 50000 Average rated hours; 5500 Lumens; Type B; Ballast Bypass; Double Ended Wiring

Specifications

General
StatusActive
Watts43
Fluorescent Equivalent54W; 59W
Volts120V-277V
Ballast TypeType B
ShapeT8
BaseSingle Pin
ANSI BaseFa8
Nominal Length96
FinishGloss White
CCT (Kelvin)4000
TemperatureCool White
CRI82
Lumens5500
Beam Spread210
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeLinear
TechnologyLED
Electrical
Watts43
Fluorescent Equivalent54W; 59W
Volts120V-277V
Ballasting RequirementsBallastBypass
Ballast TypeType B
Operating Frequency50/60 Hz
CCT (Kelvin)4000
TemperatureCool White
CRI82
Lumens5500
Beam Spread210
DimmableNon-Dimmable
Dimming TypeN/A
Power Factor0.9
Hours Rated50000
Operating Temperature-20C (-4F) to a maximum of +45C (+113F)
Physical
MOL96
MOD1
Nominal Length96
ShapeT8
BaseSingle Pin
ANSI BaseFa8
FinishGloss White
Additional Information
Shatter-Proof TypeYes
Warranty5 Year Limited - T8 LED Bulbs - Ballast Bypass
Compliance
Safety ListingcULus
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDPLQLREDLYD4V
CEC StatusLawful for sale in California
RoHS CompliantYes
NSF ApprovedYes - Approved
Packaging
Each UPC045923099182
Each Quantity1
Each Length (in.)93.78
Each Width (in.)0.98
Each Height (in.)0.98
Each Weight (lb.)0.26
Each Cube (CuFt.)0.0505
Pack TypeEgg crate
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923099189
Case Quantity10
Case Length (in.)95.70
Case Width (in.)7.68
Case Height (in.)4.33
Case Weight (lb.)13.67
Case Cube (CuFt.)1.7859
