11.5T8/LED/48-835/DR-DM - S9939
S9939

11.5T8/LED/48-835/DR-DM

Discontinued - Suggested Replacement: S49935R1
  • 11.5 Watt T8 LED
  • Medium bi-pin base
  • 3500K
  • 50000 Average rated hours
  • 1700 Lumens
location_rating^damp^1
dimmable^dimmable^2
hours_rated^50k^2
fcc_compliant^true^3
rohs_compliant^y^3
nsf_approved^y^3
S9939 SpecificationsS9939 Photometrics.iesS9939 IOTA EM Ballast Compatibility List.pdf
Tools
Lighting Layout Analysis For S9939
Create your own analysis for this Part Number
Custom Lighting Layout Analysis
Request a lighting layout
Description
Description
11.5 Watt T8 LED; Medium bi-pin base; 3500K; 50000 Average rated hours; 1700 Lumens
Products Specs
General
CompanySATCO
Lamp Ballast Type ABType A
Ballasting RequirementsMay not be compatible with all rapid start ballasts; Direct Replacement-for use on Instant Startand Rapid Start ballasts with no rewiring required
Dimmable TextOnly in Type A mode; Check Ballast MFG for Dimmer Compatibility
Lamp FilamentLED
Fixture TypeLinear
StatusDiscontinued
Most Current GenerationS49935R1
CCT SelectableNo
Wattage SelectableNo
Finish FamilyWhite
Has CameraNo
IOT EnabledNo
Lens FinishGloss White
LensedYes
Nominal Length48.0
Operating PositionUniversal
Power Factor0.96
SDS ClassLED_Lamp
Product TechnologyLED
Fluor Equiv25W-32W
Incandescent Equivalent60W
Electrical
CCT (Kelvin Temp)3500K
DimmableYes-Dimmable
Hours Rated50000
Beam Angle (degree)220
Color TempNeutral White
CRI80+
Operating Temp-20C (-4F) to +45C (+113F)
Lumens1700L
VoltsBallast Dependent
Watts11.5W
Physical
Lamp BaseMedium Bi Pin
FinishGloss White
ANSI BaseG13
Lamp TypeT8
MOD Lamps1.0
MOL48.0
Additional Info
Warranty5-Years
Installation NotesNot for use in vapor tight fixtures.
Documents
Compliance
FCC CompliantYes
Location RatingDamp
NSF ApprovedYes
ROHS CompliantYes
Safety ListingcULus
California BanLawful for sale
DLC ApprovedNo
Title 20Exempt
T24 CompliantNo
Packaging
UPC045923099397
Case Cube0.5294
Case Height3.0
Case Length48.4
Case Quantity10
Case UPC10045923099394
Case Weight6.1
Case Width6.3
EA Cube0.0276
EA Height1.0
EA Length47.7
EA Quantity1
EA Weight0.51
EA Width1.0
Inner Cube0.0
Inner Height0.0
Inner Length0.0
Inner Quantity0
Inner Weight0.0
Inner Width0.0
Pack TypeSleeve
Web Length48.0
Web Width1.0
