15T8/LED/48-835/DR - S9976
S9976

15T8/LED/48-835/DR

Discontinued - Suggested Replacement: S49976R1
  • 15 Watt T8 LED
  • 3500K
  • Medium Bi Pin base
  • 50000 Average rated hours
  • 2100 Lumens
location_rating^damp^1
hours_rated^50k^2
fcc_compliant^true^3
rohs_compliant^y^3
nsf_approved^y^3
S9976 SpecificationsS9976 Photometrics.iesS9976 Ballast Compatibility Chart.pdf
Tools
Lighting Layout Analysis For S9976
Create your own analysis for this Part Number
Custom Lighting Layout Analysis
Request a lighting layout
Description
Description
15 Watt T8 LED; 3500K; Medium Bi Pin base; 50000 Average rated hours; 2100 Lumens
Products Specs
General
CompanySATCO
Lamp FilamentLED
Fixture TypeLinear
StatusObsolete
CCT SelectableNo
Wattage SelectableNo
Finish FamilyWhite
Has CameraNo
IOT EnabledNo
Lens FinishGloss White
LensedYes
Nominal Length48.0
Operating PositionUniversal
Power Factor0.97
SDS ClassLED_Lamp
Product TechnologyLED
Fluor Equiv25W-32W
Incandescent Equivalent100W
Electrical
CCT (Kelvin Temp)3500K
DimmableNon-Dimmable
Hours Rated50000
Beam Angle (degree)220
Color TempNeutral White
CRI80+
Operating Temp-20C (-4F) to +45C (+113F)
Lumens2100L
Watts15W
Physical
Lamp BaseMedium Bi Pin
FinishGloss White
ANSI BaseG13
Lamp TypeT8
MOD Lamps1.0
MOL48.0
Additional Info
Warranty5-Years
Installation NotesNot for use in vapor tight fixtures.
Documents
Compliance
FCC CompliantYes
Location RatingDamp
NSF ApprovedYes
ROHS CompliantYes
Safety ListingcULus
California BanLawful for sale
DLC ApprovedNo
Title 20Exempt
T24 CompliantNo
Packaging
UPC045923099762
Case Cube0.5294
Case Height3.0
Case Length48.4
Case Quantity10
Case UPC10045923099769
Case Weight6.1
Case Width6.3
EA Cube0.0276
EA Height1.0
EA Length47.7
EA Quantity1
EA Weight0.51
EA Width1.0
Inner Cube0.0
Inner Height0.0
Inner Length0.0
Inner Quantity0
Inner Weight0.0
Inner Width0.0
Pack TypeSleeve
Web Length48.0
Web Width1.0
