| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type A/B |
| Ballasting Requirements | Ballast required (Type A) or Ballast Bypass (Type B) |
| Lamp Filament | LED |
| Material | Plastic |
| Fixture Type | U-Bend |
| Status | Discontinued |
| Style | Utility |
| Most Current Generation | S18414 |
| Surge Protection | Built-in-surge protection - 0.7KV |
| Total Harmonic Distortion | 20% |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | White |
| Additional Info | Replaces FB31T8/U1 |
| Amps | .15A with Electronic Ballast; .12A Ballast Bypass |
| Has Camera | False |
| IOT Enabled | False |
| Leg Spacing | 1.625 |
| Lens Finish | Frost |
| Lens Material | Plastic (PS) |
| Lensed | True |
| Nominal Length | 22.5 |
| Operating Position | Universal |
| Power Factor | 0.9 |
| SDS Class | LED_Lamp |
| Shatter Proof Type | Yes |
| Product Technology | LED |
| Fluor Equiv | 31W |
| Incandescent Equivalent | 50W |
| CCT (Kelvin Temp) | 3500K |
|---|---|
| Hours Rated | 50000 |
| Beam Angle (degree) | 160 |
| Color Temp | Neutral White |
| CRI | 80+ |
| Operating Frequency | 50/60Hz |
| Operating Temp | -25C (-13F) to +45C (+113F) |
| Lumens | 1800L |
| Volts | 120V-277V |
| Watts | 13W |
| Lamp Base | Medium Bi Pin |
|---|---|
| Finish | Frost |
| Housing Color | White |
| ANSI Base | G13 |
| Lamp Type | T8 |
| MOD Lamps | 1.0 |
| MOL | 22.59 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | True |
| CA Regulations | Exempt - Base Not Regulated |
|---|---|
| CA Status | Lawful for sale in California |
| CO Status | Lawful for sale |
| DLC ID | PLIP7GRMDBS6; PLNGZPZ9UOHF |
| FCC Compliant | True |
| HI Status | Lawful for sale |
| Location Rating | Damp |
| NV Status | Lawful for sale |
| NSF Approved | ETL Sanitation listed (conforms to NSF) |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Classified, cULus - Listed |
| CA Compliance Text | Lawful for sale |
| VT Status | Lawful for sale |
| WA Status | Lawful for sale |
| DLC Approved | True |
| Title 20 | Exempt |
| UPC | 045923184512 |
|---|---|
| Case Cube | 1.3522 |
| Case Height | 15.2 |
| Case Length | 24.4 |
| Case Quantity | 24 |
| Case UPC | 10045923184519 |
| Case Weight | 13.2 |
| Case Width | 6.3 |
| EA Cube | 0.0451 |
| EA Height | 1.2 |
| EA Length | 23.2 |
| EA Quantity | 1 |
| EA Weight | 0.58 |
| EA Width | 2.8 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Box |
| Web Length | 22.59 |
| Web Width | 1.0 |
