| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type B |
| Ballasting Requirements | Ballast Bypass- Direct wire only 100V-277V |
| Lamp Filament | LED |
| Fixture Type | Corncob |
| Status | Discontinued |
| Most Current Generation | S49393 |
| Working Voltage | AC 90-305V |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | No Finish |
| Additional Info | High Lumen Omni-directional LED for Industrial/Commercial applications; Replaces HID, CFL, and Incandescent |
| Amps | 0.450-0.162A |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | Clear |
| Lensed | True |
| Operating Position | Universal |
| Power Factor | >.9 |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Fluor Equiv | 65W |
| Incandescent Equivalent | 300W |
| CCT (Kelvin Temp) | 5000K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 40000 |
| Beam Angle (degree) | 300 |
| Color Temp | Natural Light |
| CRI | 80+ |
| Operating Frequency | 50/60Hz |
| Operating Temp | -20C (-4F) to +65C (+149F) |
| HID Equivalent | 175W |
| Lumens | 5400L |
| Volts | 120V-277V |
| Watts | 45W |
| Lamp Base | Mogul |
|---|---|
| Finish | Clear |
| Housing Color | WhiteGrey |
| ANSI Base | E39 |
| Lamp Type | Corncob |
| MOD Lamps | 3.69 |
| MOL | 10.44 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | True |
| CA Regulations | Exempt - Base Not Regulated |
|---|---|
| CA Status | Lawful for sale in California |
| CO Status | Lawful for sale |
| FCC Compliant | True |
| HI Status | Lawful for sale |
| IP Rating | IP64 |
| NV Status | Lawful for sale |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Listed |
| CA Compliance Text | Lawful for sale |
| VT Status | Lawful for sale |
| WA Status | Lawful for sale |
| DLC Approved | False |
| Title 20 | Exempt |
| T24 Compliant | False |
| UPC | 045923093531 |
|---|---|
| Case Cube | 2.5125 |
| Case Height | 24.41 |
| Case Length | 16.14 |
| Case Quantity | 12 |
| Case UPC | 10045923093538 |
| Case Weight | 30.2 |
| Case Width | 11.02 |
| EA Cube | 0.0809 |
| EA Height | 10.43 |
| EA Length | 3.66 |
| EA Quantity | 1 |
| EA Weight | 2.06 |
| EA Width | 3.66 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Box |
| Web Length | 10.44 |
| Web Width | 3.69 |
