14/T8/LED/48-840/DR - S49977
14/T8/LED/48-840/DR - S49977
14/T8/LED/48-840/DR - S49977
14/T8/LED/48-840/DR - S49977
S49977

14/T8/LED/48-840/DR

Discontinued - Suggested Replacement: S49977R1
  • 14 Watt
  • 4 Foot LED T8
  • Medium Bi Pin base
  • 4000K
  • 50000 Average rated hours
  • 2200 Lumens
  • Type A
  • Ballast dependent
location_rating^damp^1
dimmable^dimmable^2
rated_for_enclosed_fixture^true^2
hours_rated^50k^2
safety_listing^culus_list^3
fcc_compliant^true^3
rohs_compliant^y^3
nsf_approved^y^3
S49977 SpecificationsS49977 Photometrics.iesS49977 Ballast Compatibility List.pdf
Tools
Lighting Layout Analysis For S49977
Create your own analysis for this Part Number
Custom Lighting Layout Analysis
Request a lighting layout
Description
Description
14 Watt; 4 Foot LED T8; Medium Bi Pin base; 4000K; 50000 Average rated hours; 2200 Lumens; Type A; Ballast dependent
Products Specs
General
CompanySATCO
Lamp Ballast Type ABType A
Ballasting RequirementsBallast required, check compatibility
Dimmable TextOnly in Type A mode; Check Ballast MFG for Dimmer Compatibility
Lamp FilamentLED
MaterialGlass
Fixture TypeLinear
StatusDiscontinued
StyleUtility
Total Harmonic Distortion20%
Tube Guard UseApproved for use with tube guards when operated on Low or Normal ballast factor systems
CCT SelectableNo
Wattage SelectableNo
Finish FamilyWhite
Amps0.117-0.051A
Has CameraNo
IOT EnabledNo
Lens FinishGloss White
Lens MaterialGlass
Nominal Length48.0
Operating PositionUniversal
Power Factor0.9
SDS ClassLED_Lamp
Indoor OutdoorIndoor
Product TechnologyLED
Fluor Equiv32W/30W/28W/25W
Incandescent Equivalent175W
Electrical
CCT (Kelvin Temp)4000K
DimmableYes-Dimmable
Hours Rated50000
Beam Angle (degree)210
Color TempCool White
CRI80+
Operating Frequency50/60Hz
Operating Temp-20C (-4F) to +45C (+113F)
Lumens2200L
VoltsBallast Dependent
Watts14W
Physical
Lamp BaseMedium Bi Pin
FinishGloss White
Housing ColorWhite
ANSI BaseG13
Lamp TypeT8
MOD Lamps1.1
MOL47.78
Additional Info
Warranty5-Years
Installation NotesNot for use in vapor tight fixtures.
Rated For Enclosed FixtureYes
Documents
Compliance
DLC IDPLWBOVBQ1FUI
FCC CompliantYes
Location RatingDamp
NSF ApprovedYes
ROHS CompliantYes
Safety ListingcULus - Certified, cULus - Listed
California BanLawful for sale
DLC ApprovedYes
Title 20Exempt
T24 CompliantNo
Packaging
UPC045923499777
Case Cube0.9868
Case Height5.91
Case Length48.82
Case Quantity25
Case UPC10045923499774
Case Weight14.4
Case Width5.91
EA Cube0.0336
EA Height48.0
EA Length1.1
EA Quantity1
EA Weight0.44
EA Width1.1
Inner Cube0.0
Inner Height0.0
Inner Length0.0
Inner Quantity0
Inner Weight0.0
Inner Width0.0
Pack TypeSleeve
Web Length47.78
Web Width1.1
