| Company | SATCO |
|---|---|
| Dimmable Text | Reverse Phase |
| Lamp Filament | LED |
| Fixture Type | Miniature |
| Status | Discontinued |
| Style | Utility |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | No Finish |
| Additional Info | Solid State LED lighting. 40W Halogen replacement |
| Amps | 0.033-0.031A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | Clear |
| Lensed | Yes |
| Operating Position | Universal |
| Power Factor | 0.9 |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Fluor Equiv | 35W-50W |
| Incandescent Equivalent | 25W |
| CCT (Kelvin Temp) | 3000K |
|---|---|
| Dimmable | Yes-Dimmable |
| Hours Rated | 25000 |
| Beam Angle (degree) | 360 |
| Color Temp | Warm White |
| CRI | 80+ |
| Dimming Type | 120V only, Phase cut |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Lumens | 480L |
| Volts | 120V-130V |
| Watts | 4W |
| Lamp Base | G9 Double Loop |
|---|---|
| Finish | Clear |
| Housing Color | None |
| ANSI Base | G9 |
| Lamp Type | T4 |
| MOD Lamps | 0.5 |
| MOL | 2.38 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | Yes |
| FCC Compliant | Yes |
|---|---|
| Location Rating | Damp |
| ROHS Compliant | Yes |
| Safety Listing | cETLus - Listed |
| California Ban | Lawful for sale |
| DLC Approved | No |
| Title 20 | Exempt |
| T24 Compliant | No |
| UPC | 045923286025 |
|---|---|
| Case Cube | 1.0318 |
| Case Height | 7.25 |
| Case Length | 18.38 |
| Case Quantity | 48 |
| Case UPC | 10045923286022 |
| Case Weight | 5.94 |
| Case Width | 13.38 |
| EA Cube | 0.0113 |
| EA Height | 6.0 |
| EA Length | 0.79 |
| EA Quantity | 1 |
| EA Weight | 0.03 |
| EA Width | 4.13 |
| Inner Cube | 0.2057 |
| Inner Height | 6.5 |
| Inner Length | 8.75 |
| Inner Quantity | 12 |
| Inner UPC | 20045923286029 |
| Inner Weight | 1.09 |
| Inner Width | 6.25 |
| Pack Type | Carded |
| Web Length | 2.38 |
| Web Width | 0.5 |
