| Company | SATCO |
|---|---|
| Lamp Filament | LED |
| Fixture Type | Miniature |
| Status | Obsolete |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | No Finish |
| Amps | 0.042A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | Clear |
| Lensed | Yes |
| Operating Position | Universal |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Incandescent Equivalent | 40W |
| CCT (Kelvin Temp) | 3000K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 15000 |
| Beam Angle (degree) | 360 |
| Color Temp | Warm White |
| CRI | 80+ |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Lumens | 450L |
| Volts | 120v |
| Watts | 5W |
| Lamp Base | G9 Double Loop |
|---|---|
| Finish | Clear |
| Housing Color | White |
| ANSI Base | G9 |
| Lamp Type | T4 |
| MOD Lamps | 1.56 |
| MOL | 2.38 |
| Warranty | 2-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. Not for use in totally enclosed fixtures |
| FCC Compliant | Yes |
|---|---|
| ROHS Compliant | Yes |
| California Ban | Lawful for sale |
| DLC Approved | No |
| Title 20 | Exempt |
| T24 Compliant | No |
| UPC | 045923092268 |
|---|---|
| Case Cube | 0.6915 |
| Case Height | 6.69 |
| Case Length | 18.9 |
| Case Quantity | 100 |
| Case UPC | 10045923092265 |
| Case Weight | 15.64 |
| Case Width | 9.45 |
| EA Cube | 0.0037 |
| EA Height | 2.56 |
| EA Length | 1.58 |
| EA Quantity | 1 |
| EA Weight | 0.14 |
| EA Width | 1.58 |
| Inner Cube | 0.1073 |
| Inner Height | 5.91 |
| Inner Length | 8.86 |
| Inner Quantity | 20 |
| Inner UPC | 20045923092262 |
| Inner Weight | 3.0 |
| Inner Width | 3.54 |
| Pack Type | Box |
| Web Length | 2.38 |
| Web Width | 1.56 |
