| Status | Discontinued |
| Substitute | S29004 |
| Watts | 3W |
| Incandescent Equivalent | 20W |
| Volts | 12V |
| Shape | R12 |
| Base | Bayonet Single Contact |
| ANSI Base | BA15s |
| Finish | Frost |
| CCT (Kelvin) | 3000K |
| Temperature | Warm White |
| CRI | 80+ |
| Lumens | 120L |
| Beam Spread | 40 |
| Dimmable | Non-Dimmable |
| Hours Rated | 30000 |
| Product Category | Miniature |
| Lamp Type | Miniature |
| Technology | LED |
| Watts | 3W |
| Incandescent Equivalent | 20W |
| Volts | 12V |
| Working Voltage | 12V AC/DC |
| CCT (Kelvin) | 3000K |
| Temperature | Warm White |
| CRI | 80+ |
| Lumens | 120L |
| Beam Spread | 40 |
| Dimmable | Non-Dimmable |
| Hours Rated | 30000 |
| Operating Temperature | -20C (-4F) to +45C (+113F) |
| MOL | 2.5 |
| MOD | 1.5 |
| Shape | R12 |
| Base | Bayonet Single Contact |
| ANSI Base | BA15s |
| Finish | Frost |
| Housing Color | Silver |
| Warranty | 5 Years |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| SDS Sheet | LED Lamp |
| Each UPC | 045923090042 |
| Each Quantity | 1 |
| Each Length (in.) | 1.63 |
| Each Width (in.) | 1.63 |
| Each Height (in.) | 3.19 |
| Each Weight (lb.) | 0.08 |
| Each Cube (CuFt.) | 0.0049 |
| Pack Type | Box |
| Inner UPC | 20045923090046 |
| Inner Quantity | 12 |
| Inner Length (in.) | 16.20 |
| Inner Width (in.) | 12.40 |
| Inner Height (in.) | 7.40 |
| Inner Weight (lb.) | 1.29 |
| Inner Cube (CuFt.) | 0.8602 |
| Case UPC | 10045923090049 |
| Case Quantity | 48 |
| Case Length (in.) | 26.30 |
| Case Width (in.) | 17.70 |
| Case Height (in.) | 16.80 |
| Case Weight (lb.) | 5.96 |
| Case Cube (CuFt.) | 4.5258 |
