Discontinued – Suggested Replacement: S9636
S9146 12BR40/LED/4000K/970L/120V/D

S9146

12BR40/LED/4000K/970L/120V/D

12 watt; LED BR40; 4000K; 103' beam spread; Medium base; 120 volts; dimmable


Lights

S9146

12BR40/LED/4000K/970L/120V/D

12 watt; LED BR40; 4000K; 103' beam spread; Medium base; 120 volts; dimmable

Specifications

General
StatusDiscontinued
SubstituteS9636
Watts12W
Incandescent Equivalent65W
Volts120V
ShapeBR40
BaseMedium
ANSI BaseE26
FinishFrost
CCT (Kelvin)4000K
TemperatureCool White
CRI80
Lumens970L
Beam Spread103
DimmableYes-Dimmable
Hours Rated25000
Product CategoryReflector
Lamp TypeReflector
TechnologyLED
Electrical
Watts12W
Incandescent Equivalent65W
Volts120V
CCT (Kelvin)4000K
TemperatureCool White
CRI80
Lumens970L
Candlepower340
Beam Spread103
DimmableYes-Dimmable
Hours Rated25000
Operating Temperature-20C (-4F) to +45C (+113F)
Physical
MOL6.5
MOD5
ShapeBR40
BaseMedium
ANSI BaseE26
FinishFrost
LensedLensed Lamp
Lens FinishFrost
Lens MaterialPlastic (PS)
Housing ColorGray
Additional Information
Warranty3 Year Limited
Compliance
Safety ListingcULus
Location RatingDamp
Energy StarNo
California Compliant SubstituteS8493
RoHS CompliantYes
FCC CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923091469
Each Quantity1
Each Length (in.)5.12
Each Width (in.)5.12
Each Height (in.)6.81
Each Weight (lb.)0.78
Each Cube (CuFt.)0.1033
Pack TypeBox
Inner UPC20045923091463
Inner Quantity6
Inner Length (in.)15.87
Inner Width (in.)10.63
Inner Height (in.)7.20
Inner Weight (lb.)5.20
Inner Cube (CuFt.)0.7029
Case UPC10045923091466
Case Quantity12
Case Length (in.)22.13
Case Width (in.)16.54
Case Height (in.)8.27
Case Weight (lb.)11.42
Case Cube (CuFt.)1.7518
×

Dimmer Compatibility

Type Brand Model Number Website
Dimmer Leviton 6674 Visit
Dimmer Leviton IPL06-10 Visit
Dimmer Lutron SLV-600P Visit
×
×

Precautions

No precautions available at this time.

×
