Discontinued – Suggested Replacement: S49948
S9948 8T8/LED/24-840/DR

S9948

8T8/LED/24-840/DR

8 Watt T8 LED; 4000K; Medium Bi Pin base; 50000 Average rated hours; 1250 Lumens; Type A; Ballast dependent


Lights

S9948

8T8/LED/24-840/DR

8 Watt T8 LED; 4000K; Medium Bi Pin base; 50000 Average rated hours; 1250 Lumens; Type A; Ballast dependent

Specifications

General
StatusDiscontinued
SubstituteS49948
Watts8W
Incandescent Equivalent60W
Fluorescent Equivalent17W
VoltsBallast Dependent
Ballast TypeType A
ShapeT8
BaseMedium Bi Pin
ANSI BaseG13
Nominal Length24
FinishGloss White
CCT (Kelvin)4000K
TemperatureCool White
CRI80+
Lumens1250L
Beam Spread220
DimmableNon-Dimmable
Hours Rated50000
Product CategoryLinear
Lamp TypeLinear
TechnologyLED
Electrical
Watts8W
Incandescent Equivalent60W
Fluorescent Equivalent17W
VoltsBallast Dependent
Ballasting RequirementsBallast required
Ballast TypeType A
CCT (Kelvin)4000K
TemperatureCool White
CRI80+
Lumens1250L
Beam Spread220
DimmableNon-Dimmable
Power Factor0.96
Hours Rated50000
Operating Temperature-20C (-4F) to +45C (+113F)
Physical
MOL24
MOD1
Nominal Length24
ShapeT8
BaseMedium Bi Pin
ANSI BaseG13
FinishGloss White
Lens FinishGloss White
Additional Information
Installation NotesNot for use in vapor tight fixtures.
Rated For Enclosed FixtureYes
Warranty5-Years
Compliance
Safety ListingcULus
Location RatingDamp
DLC ApprovedNo
RoHS CompliantYes
FCC CompliantYes
NSF ApprovedYes
SDS SheetLED Lamp
Packaging
Each UPC045923099489
Each Quantity1
Each Length (in.)23.80
Each Width (in.)1.00
Each Height (in.)1.00
Each Weight (lb.)0.28
Each Cube (CuFt.)0.0138
Pack TypeSleeve
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923099486
Case Quantity10
Case Length (in.)24.40
Case Width (in.)6.30
Case Height (in.)3.00
Case Weight (lb.)3.40
Case Cube (CuFt.)0.2669
×
×

Ballast Compatibility

Name Type View
Emergency Ballast IOTA LED T8 View
T8 LED Chart C LED T8 View
T8 LED Chart H LED T8 View
T8 LED Emergency Chart H LED T8 View
×

Precautions

No precautions available at this time.

×
