S16511

FC12T9/LED/CIR/CCT/DM/A-B

  • LED Circline
  • 16 Watt
  • T9
  • 3000K/4000K/6500K CCT Selectable
  • G10q Base
  • 120-277 Volt
location_rating^damp^1
cc_selectable^y^1
rated_for_enclosed_fixture^true^2
hours_rated^50k^2
fcc_compliant^true^3
rohs_compliant^y^3
S16511 SpecificationsS16511 InstructionsS16511 Ballast Compatibility Chart
Description
Description
LED Circline; 16 Watt; T9; 3000K/4000K/6500K CCT Selectable; G10q Base; 120-277 Volt
Products Specs
General
CompanySATCO
Lamp Ballast Type ABType A/B
Ballasting RequirementsBallast required (Type A, Electronic only) or Ballast Bypass (Type B)
CA RegulationsExempt - Base Not Regulated
Lamp FilamentLED
MaterialPolycarbonate (PC)
Fixture TypeCircline
Product NotesOnly compatible with Electronic ballasts when installed in Type A mode. See ballast compatibility list for details. Not for use on magnetic ballasts.; Inner Diameter: 9.45 in.
StatusActive
StyleUtility
Surge ProtectionBuilt-in surge protection - 2.5KV
Total Harmonic Distortion25%
CCT SelectableTrue
Wattage SelectableFalse
Finish FamilyFrost
Amps0.133-0.058A
Has CameraFalse
IOT EnabledFalse
Lens FinishFrost
Minimum Compartment SizeLength 14.1 in. Width 14.1 in. Height: 3.5 in.
SDS ClassLED_Lamp
Indoor OutdoorIndoor
Product TechnologyLED
Fluor Equiv32W
Incandescent Equivalent50W
Electrical
CCT (Kelvin Temp)3000K/4000K/6500K
DimmableNon-Dimmable
Hours Rated50000
Beam Angle (degree)180
Color TempSoft White to Daylight
CRI80+
Operating Frequency50/60Hz
Operating Temp-20C (-4F) to +45C (+113F)
Lumens1850L/2000L/1950L
Volts120V-277V
Watts16W
Physical
Lamp BaseG10q (4-Pin)
FinishFrost
Housing ColorFrost
ANSI BaseG10q
Lamp TypeT9
MOD Lamps1.2
MOL11.82
Additional Info
Warranty5-Years
Installation NotesNot for use in vapor tight fixtures.
Rated For Enclosed FixtureTrue
Documents
Compliance
CA StatusLawful for sale in California
FCC CompliantTrue
Location RatingDamp
ROHS CompliantYes
Safety ListingcETLus - Classified
CA Compliance TextLawful for sale
DLC ApprovedFalse
Title 20Exempt
T24 CompliantFalse
Packaging
UPC045923165115
Case Cube1.5412
Case Height12.4
Case Length17.32
Case Quantity12
Case UPC10045923165112
Case Weight11.73
Case Width12.4
EA Cube0.1152
EA Height12.01
EA Length12.01
EA Quantity1
EA Weight0.57
EA Width1.38
Inner Cube0.0
Pack TypeBox
Web Length11.82
Web Width1.2
