| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type A |
| Ballasting Requirements | May not be compatible with all rapid start ballasts; Direct Replacement-for use on Instant Startand Rapid Start ballasts with no rewiring required |
| Lamp Filament | LED |
| Fixture Type | U-Bend |
| Status | Obsolete |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | White |
| Has Camera | No |
| IOT Enabled | No |
| Leg Spacing | 6.0 |
| Lens Finish | Gloss White |
| Lensed | Yes |
| Nominal Length | 22.5 |
| Operating Position | Universal |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Fluor Equiv | 32W |
| Incandescent Equivalent | 60W |
| CCT (Kelvin Temp) | 5000K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 230 |
| Color Temp | Natural Light |
| CRI | 80+ |
| Operating Temp | -4F to +113F (-20C to +45C) |
| Lumens | 1800L |
| Volts | Ballast Dependent |
| Watts | 12W |
| Lamp Base | Medium Bi Pin |
|---|---|
| Finish | Gloss White |
| ANSI Base | G13 |
| Lamp Type | T8 |
| MOD Lamps | 1.0 |
| MOL | 22.5 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| FCC Compliant | Yes |
|---|---|
| Location Rating | Damp |
| NSF Approved | Yes |
| ROHS Compliant | Yes |
| Safety Listing | cULus |
| California Ban | Lawful for sale |
| DLC Approved | No |
| Title 20 | Exempt |
| T24 Compliant | No |
| UPC | 045923092978 |
|---|---|
| Case Cube | 2.0847 |
| Case Height | 9.5 |
| Case Length | 24.0 |
| Case Quantity | 12 |
| Case UPC | 10045923092975 |
| Case Weight | 10.8 |
| Case Width | 15.8 |
| EA Cube | 0.1309 |
| EA Height | 1.3 |
| EA Length | 23.2 |
| EA Quantity | 1 |
| EA Weight | 0.7 |
| EA Width | 7.5 |
| Pack Type | Box |
| Web Length | 22.5 |
| Web Width | 1.0 |
