| Company | NUVO |
|---|---|
| Bulb Included | Integrated |
| Fixture Type | Step Light |
| Status | Discontinued |
| Style | Utility |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | Gray |
| Amps | 0.011A |
| Has Camera | No |
| IOT Enabled | No |
| SDS Class | LED_Fixture |
| Product Technology | LED |
| Incandescent Equivalent | 25W |
| CCT (Kelvin Temp) | 3000K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Color Temp | Warm White |
| CRI | 80+ |
| Lumens | 220L |
| Volts | 277V |
| Watts | 3W |
| Connection | Hardwire |
| Lamp Base | Integrated |
|---|---|
| Finish | Gray |
| ANSI Base | Integrated |
| Lamp Type | Integrated LED |
| Mounting Procedure | Vertical Step Strip |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not concrete rated; Requires a recessed switch box with a minimum interior box volume of 13 cubic inches. |
| CA Prop 65 | Lead |
|---|---|
| FCC Compliant | Yes |
| Location Rating | Wet |
| ROHS Compliant | Yes |
| Safety Listing | cULus |
| California Ban | Lawful for sale |
| DLC Approved | No |
| Title 20 | Exempt |
| T24/JA8 Compliant | No |
| UPC | 045923554100 |
|---|---|
| Case Cube | 0.5078 |
| Case Height | 8.8 |
| Case Length | 31.16 |
| Case Quantity | 24 |
| Case UPC | 10045923554107 |
| Case Weight | 13.2 |
| Case Width | 3.2 |
| EA Cube | 0.0212 |
| EA Height | 2.2 |
| EA Length | 5.2 |
| EA Quantity | 1 |
| EA Weight | 0.45 |
| EA Width | 3.2 |
| Pack Type | Box |
| Web Height | 5.0 |
| Web Length | 1.63 |
| Web Width | 3.0 |
