| Company | NUVO |
|---|---|
| Bulb Included | Integrated |
| Dimmable Text | 0-10V Dimming |
| Material | Die-cast Aluminum |
| Fixture Type | Canopy |
| Product Notes | Multiple half-inch knockouts; Three quarter inch back knockout for pendant applications |
| Status | Active |
| Style | Utility |
| Surge Protection | Built-in surge protection - 2.5KV |
| Total Harmonic Distortion | <20% |
| CCT Selectable | True |
| Wattage Selectable | True |
| Finish Family | White |
| Additional Info | Recommended Mounting Height: 9 to 15 Feet |
| Amps | 0.167-0.072/0.250-0.108/0.375-0.162A |
| Has Camera | False |
| Integrated Features | Integrated DC Sensor Port |
| IOT Enabled | False |
| Lens Material | Polycarbonate (PC) |
| Photo Cell | Optional Add-On |
| Power Factor | >0.9 |
| SDS Class | LED_Fixture |
| Indoor Outdoor | Outdoor |
| Product Technology | LED |
| Incandescent Equivalent | 100W |
| CCT (Kelvin Temp) | 3000K/4000K/5000K |
|---|---|
| Dimmable | Yes-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 190 |
| Color Temp | Warm White to Natural Light |
| CRI | 80+ |
| Operating Frequency | 50/60Hz |
| Operating Temp | -40C (-40F) to +50C (+122F) |
| Lumens | 2663L-6288L |
| Volts | 120V-277V |
| Watts | 20W/30W/45W |
| Lamp Base | Integrated |
|---|---|
| Finish | WHITE |
| ANSI Base | Integrated |
| Lamp Type | Integrated LED |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Hinged door for ease of installation |
| Bug Rating | B2-U3-G3 |
|---|---|
| CA Regulations | T20 Exempt - Fixtures Not Regulated |
| CA Prop 65 | Lead |
| CA Status | Lawful for sale in California |
| DLC ID | S-32C65E |
| FCC Compliant | True |
| IP Rating | IP65 |
| Location Rating | Wet |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified |
| CA Compliance Text | Lawful for sale |
| DLC Approved | True |
| Title 20 | Exempt |
| T24 Compliant | False |
| UPC | 045923654176 |
|---|---|
| Case Cube | 1.6806 |
| Case Height | 11.81 |
| Case Length | 21.18 |
| Case Quantity | 4 |
| Case UPC | 10045923654173 |
| Case Weight | 20.68 |
| Case Width | 11.61 |
| EA Cube | 0.3598 |
| EA Height | 11.02 |
| EA Length | 11.02 |
| EA Quantity | 1 |
| EA Weight | 4.73 |
| EA Width | 5.12 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Brown Box |
| Web Height | 3.62 |
| Web Length | 9.57 |
| Web Width | 9.57 |
