LED UFO HIGHBAY CCT & WATT ADJ - 65-770
LED UFO HIGHBAY CCT & WATT ADJ - 65-770
LED UFO HIGHBAY CCT & WATT ADJ - 65-770
LED UFO HIGHBAY CCT & WATT ADJ - 65-770
LED UFO HIGHBAY CCT & WATT ADJ - 65-770
65-770

LED UFO HIGHBAY CCT & WATT ADJ

Discontinued - Suggested Replacement: 65-770R3
  • LED UFO High Bay
  • CCT Selectable 3K/4K/5K and Wattage Selectable 80W/100W/120W
  • 50,000 hours working life
  • Black Finish
cc_selectable^y^1
ip_rating^IP65^1
location_rating^wet^2
dimmable^dimmable^2
hours_rated^50k^2
warranty^5_years^2
volts^120-277v^2
dimmable_text^0-10_dim^2
fcc_compliant^true^3
rohs_compliant^y^3
nsf_approved^y^3
65-770 Specifications65-770 How To Bypass The Sensor.pdf
Tools
Lighting Layout Analysis For 65-770
Create your own analysis for this Part Number
Custom Lighting Layout Analysis
Request a lighting layout
Description
Description
Introducing 65-770, our newest wattage and CCT selectable UFO. With a wattage selectability of 80W/100W/120W and CCT selectability of 3000K/4000K/5000K, this fixture can meet all your lighting needs. Other features include an integrated sensor port for easy field installation of an add on microwave sensor, a 90-degree beam angle, a locking hook, an IP65 rating, 0-10V dimmability and 4KV surge protection. This product is rated for 50,000 hours and carries a 5-year warranty. Offered with this a full suite of accessories including yoke mounts, pendant adapters, protective cages, anti-glare shields, a sensor and remote and an add on EM.
Products Specs
General
CompanyNUVO
Bulb IncludedIntegrated
Diameter12.2
MaterialDie-cast Aluminum
Fixture TypeUFO Hi-Bay
StatusObsolete
Surge ProtectionBuilt-in surge protection - 4KV
Total Harmonic Distortion15%
Wire Length72.0
CCT SelectableYes
Wattage SelectableYes
Finish FamilyBlack
Amps0.667-0.289/0.833-0.361/1.000-0.433A
Has CameraNo
IOT EnabledNo
Lens FinishClear
Lens MaterialPolycarbonate (PC)
SDS ClassLED_Fixture
Sloped Ceiling CompatibleNo
Indoor OutdoorIndoor
Product TechnologyLED
Incandescent Equivalent500W/600W/1000W
Electrical
CCT (Kelvin Temp)3000K/4000K/5000K
DimmableYes-Dimmable
Hours Rated50000
Beam Angle (degree)90
Color TempWarm to Cool White
CRI80+
Dimming Type0-10V Dimming
Operating Temp-40F to +131F (-40C to +55C)
HID Equivalent150W/250W
Lumens11840L-18600L
Volts120V-277V
Watts80W/100W/120W
Max Lumens18600L
Physical
Lamp BaseIntegrated
FinishBLACK
Housing ColorBlack
ANSI BaseIntegrated
Lamp TypeIntegrated LED
Fixture ShapeRound
Mounting ProcedureCeiling
Additional Info
Warranty5-Years
Documents
Compliance
CA Prop 65Lead
DLC IDPL2MBEOW4AJJ
FCC CompliantYes
IP RatingIP65
Location RatingWet
NSF ApprovedYes
ROHS CompliantYes
Safety ListingcULus - Certified
California BanLawful for sale
DLC ApprovedYes
Title 20Exempt
T24/JA8 CompliantNo
Packaging
UPC045923665677
Case Cube1.0106
Case Height7.72
Case Length15.04
Case Quantity1
Case UPC10045923665674
Case Weight8.6
Case Width15.04
EA Cube1.0106
EA Height7.72
EA Length15.04
EA Quantity1
EA Weight8.6
EA Width15.04
Pack TypeBox
Web Height8.46
Web Width12.2
