87-501

DOMINO 3 BUTTON WIRELESS KEYPA

  • DOMINO
  • 3 Button Wireless Keypad with Wall Plate
ip_rating^IP20^1
dimmable^dimmable^2
warranty^5_years^2
dimmable_text^0-10_dim^2
fcc_compliant^true^3
rohs_compliant^y^3
Description
Description
The DOMINO 87-501 3-Button Keypad is a compact, battery-powered interface for wireless control of DOMINO-enabled lighting devices within a networked lighting control system. It enables basic on/off switching, brightness adjustment via dimming, and direct control of individual devices or groups. Powered by a long-life CR2032 battery, the keypad can be surface-mounted, installed in a standard switch box, or used as a handheld remote. Configured through the DOMINO app, it offers flexible, wire-free control for a wide range of commercial applications.
Products Specs
General
CompanyNUVO
Starfish Communication ProtocolDomino Bluetooth Mesh 2.4 GHz
MaterialThermo Plastic
StatusActive
Working Voltage3V
Finish FamilyWhite
Has CameraNo
Photo CellNo
Starfish Software SupportedDOMINO App
Starfish Software UpgradeableYes
Indoor OutdoorIndoor
Product TechnologyNot Applicable
Electrical
DimmableYes-Dimmable
Dimming Type0-10V Dimming, Phase cut
Operating Temp+32F to +86F (0C to +30C)
Volts3V
Replaceable Battery TypeCR2032
Physical
FinishWHITE
Mounting ProcedureWall
Additional Info
Warranty5-Years
Compliance
CA Prop 65Lead
FCC CompliantYes
IP RatingIP20
Location RatingDry
ROHS CompliantYes
Safety ListingcULus
Packaging
UPC045923875014
Case Cube1.1662
Case Height5.91
Case Length21.65
Case Quantity100
Case UPC10045923875011
Case Weight8.98
Case Width15.75
EA Cube0.0096
EA Height0.98
EA Length5.59
EA Quantity1
EA Weight0.07
EA Width3.03
Pack TypeBrown Box
Web Height5.0
Web Length3.0
Web Width0.25
