| Company | SATCO |
|---|---|
| Bulb Included | Integrated |
| Material | Aluminum / Plastic |
| Fixture Type | Direct Wire LED Downlight |
| Status | Discontinued |
| Style | Utility |
| CCT Selectable | Yes |
| Wattage Selectable | No |
| Finish Family | White |
| Amps | 0.167A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Material | Polycarbonate (PC) |
| Minimum Compartment Size | Length: 23.6 in. Width: 7.87 in. Height: 4.72 in. |
| Power Factor | >0.9 |
| SDS Class | LED_Lamp |
| Sloped Ceiling Compatible | Yes |
| Indoor Outdoor | Indoor |
| Product Technology | LED |
| Incandescent Equivalent | 100W |
| CCT (Kelvin Temp) | 3000K/4000K/5000K |
|---|---|
| Dimmable | Yes-Dimmable |
| Hours Rated | 40000 |
| Beam Angle (degree) | 110 |
| Color Temp | Warm to Cool White |
| CRI | 90+ |
| Dimming Type | 120V only, Phase Cut (TRIAC) |
| Operating Frequency | 60Hz |
| Operating Temp | -4F to +113F (-20C to +45C) |
| Lumens | 1500L |
| Volts | 120v |
| Watts | 20W |
| Connection | Direct Wired |
| Lamp Base | Integrated |
|---|---|
| Finish | WHITE |
| ANSI Base | Integrated |
| Lamp Type | Integrated LED |
| Fixture Shape | Linear |
| Mounting Procedure | Ceiling/Wall |
| Warranty | 5-Years |
|---|
| Air Tight | Yes |
|---|---|
| CA Prop 65 | Lead |
| FCC Compliant | Yes |
| IC Rated | Yes |
| Location Rating | Damp |
| ROHS Compliant | Yes |
| Safety Listing | cETLus - Listed |
| California Ban | California T24 Listed |
| UL Application | Ceiling / Wall |
| DLC Approved | No |
| Energy Star Certified | No |
| Title 20 | Exempt |
| T24/JA8 Compliant | Yes |
| UPC | 045923117220 |
|---|---|
| Case Cube | 3.5689 |
| Case Height | 16.5 |
| Case Length | 25.6 |
| Case Quantity | 12 |
| Case UPC | 10045923117227 |
| Case Weight | 27.56 |
| Case Width | 14.6 |
| EA Cube | 0.1636 |
| EA Height | 3.15 |
| EA Length | 24.0 |
| EA Quantity | 1 |
| EA Weight | 2.13 |
| EA Width | 3.74 |
| Pack Type | Box |
| Web Height | 3.15 |
| Web Length | 24.0 |
| Web Width | 3.74 |
