» S11932

S11932 8T8/LED/24-840/XD

S11932

8T8/LED/24-840/XD

8 Watt T8 LED; 4000K; 120-277 Volt; Medium Bi Pin base; Type C; External Driver required


SATCO|NUVO's 8-watt LED T8 bulb is an ideal lighting solution for a variety of applications. This easy to install, low maintenance lamp has a 220-degree beam spread and high lumens count for superior illumination. Dimmable and versatile, this lamp delivers 50,000 hours of cool white light.
  • Cool white light
  • Damp rated for indoor use
  • Enclosed Rated Lamp
  • L:24.00 D:1.00
  • T8, Frosted Finish
Lights

S11932

8T8/LED/24-840/XD

8 Watt T8 LED; 4000K; 120-277 Volt; Medium Bi Pin base; Type C; External Driver required

SATCO|NUVO's 8-watt LED T8 bulb is an ideal lighting solution for a variety of applications. This easy to install, low maintenance lamp has a 220-degree beam spread and high lumens count for superior illumination. Dimmable and versatile, this lamp delivers 50,000 hours of cool white light.
  • Cool white light
  • Damp rated for indoor use
  • Enclosed Rated Lamp
  • L:24.00 D:1.00
  • T8, Frosted Finish

Specifications

General
StatusActive
Watts8W
Incandescent Equivalent40W
Fluorescent Equivalent17W
Volts120V-277V
Ballast TypeType C
ShapeT8
BaseMedium Bi Pin
ANSI BaseG13
Nominal Length24
FinishFrost
CCT (Kelvin)4000K
TemperatureCool White
CRI82
Lumens1200L
Beam Spread220
DimmableYes-Dimmable
Hours Rated50000
Product CategoryLinear
Lamp TypeLinear
TechnologyLED
Electrical
Watts8W
Incandescent Equivalent40W
Fluorescent Equivalent17W
Volts120V-277V
Ballasting RequirementsBallast replaced with external driver
Ballast TypeType C
Operating Frequency50/60Hz
CCT (Kelvin)4000K
TemperatureCool White
CRI82
Lumens1200L
Beam Spread220
DimmableYes-Dimmable
Dimming Note0-10V Dimming Only
Power Factor0.9
Hours Rated50000
THD20%
Operating Temperature-20C (-4F) to +45C (+113F)
Physical
MOL24
MOD1
Nominal Length24
ShapeT8
BaseMedium Bi Pin
ANSI BaseG13
FinishFrost
MaterialGlass
Lens FinishFrost
Weight (lb.)0.25
Additional Information
Additional InfoNot for emergency lighting
Tube Guard UseApproved for use with tube guards
Installation NotesNot for use in vapor tight fixtures.
Rated For Enclosed FixtureYes
Warranty5 Year Limited - LED Type C Bulbs
Compliance
Safety ListingcULus - Classified; cULus - Certified
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDPL7QH6B0982C
CA T20 / T24 RationaleExempt - Base Not Regulated
RoHS CompliantYes
FCC CompliantYes
NSF ApprovedETL Sanitation listed (conforms to NSF)
SDS SheetLED Lamp
Packaging
Each UPC045923119323
Each Quantity1
Each Length (in.)23.70
Each Width (in.)1.00
Each Height (in.)1.00
Each Weight (lb.)0.25
Each Cube (CuFt.)0.0137
Pack TypeSleeve
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923119320
Case Quantity25
Case Length (in.)23.62
Case Width (in.)5.90
Case Height (in.)5.90
Case Weight (lb.)6.88
Case Cube (CuFt.)0.4758
