S13150 72W/LED/HID-HB/840/120-277V/DI

S13150

72W/LED/HID-HB/840/120-277V/DI

72 Watt - LED HID Replacement; 4K; EX39; Type B Ballast Bypass; 120-277 Volt; Dimmable


Satco's 72-watt high bay LED lamp is a versatile and efficient lighting solution for those difficult lighting situations. Illuminate warehouses, gymnasiums, health clubs, and factories with this high lumen, LED lamp. Reduce maintenance and energy costs with this dimmable lamp rated for 50,000 hours of cool white light.
  • 4000K Cool White Light
  • Advanced Passive Heat Dissipation
  • Wide, 180 degree Beam Angle
  • Long neck design fits more fixtures
  • 6kV built-in surge protection
  • Rated for use in enclosed fixtures
  • Lawful for sale in California
Lights

S13150

72W/LED/HID-HB/840/120-277V/DI

72 Watt - LED HID Replacement; 4K; EX39; Type B Ballast Bypass; 120-277 Volt; Dimmable

Satco's 72-watt high bay LED lamp is a versatile and efficient lighting solution for those difficult lighting situations. Illuminate warehouses, gymnasiums, health clubs, and factories with this high lumen, LED lamp. Reduce maintenance and energy costs with this dimmable lamp rated for 50,000 hours of cool white light.
  • 4000K Cool White Light
  • Advanced Passive Heat Dissipation
  • Wide, 180 degree Beam Angle
  • Long neck design fits more fixtures
  • 6kV built-in surge protection
  • Rated for use in enclosed fixtures
  • Lawful for sale in California

Specifications

General
StatusActive
Watts72W
Incandescent Equivalent400W
Fluorescent Equivalent100W
HID Equivalent320W
Volts120V-277V
ShapeHB51
BaseMogul Extended
ANSI BaseEX39
FinishWhite
CCT (Kelvin)4000K
TemperatureCool White
CRI82
Lumens11000L
Beam Spread180
DimmableYes-Dimmable
Hours Rated50000
Lamp TypeHi-Bay Flood
TechnologyLED
Min Compartment SizeDiameter: 11.81 in. Height: 13.78 in.
Ballasting RequirementsBallast Bypass
Electrical
Watts72W
Incandescent Equivalent400W
Fluorescent Equivalent100W
HID Equivalent320W
Volts120V-277V
Ballasting RequirementsBallast Bypass
Operating Frequency50/60 Hz
CCT (Kelvin)4000K
TemperatureCool White
CRI82
Lumens11000L
Beam Spread180
DimmableYes-Dimmable
Power Factor0.9
Hours Rated50000
Burning PositionBase Up
Surge ProtectionBuilt-in surge protection - 6KV
THD20%
Operating Temperature-40C (-40F) to +60C (+140F)
Physical
MOL8.15
MOD6.34
ShapeHB51
BaseMogul Extended
ANSI BaseEX39
FinishWhite
Lens FinishClear
Lens MaterialGlass
Housing ColorWhite
Weight (lb.)2.09
Additional Information
Min Compartment SizeDiameter: 11.81 in. Height: 13.78 in.
Rated For Enclosed FixtureYes
IP RatingIP40
Installation NotesVertical Only
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus - Listed
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDP49DFZQC
CA T20 / T24 RationaleExempt - Base Not Regulated
NSF ApprovedYes
California StatusLawful for sale in California
Title 20 / 24 StatusLawful for sale
RoHS CompliantYes
FCC CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923131509
Each Quantity1
Each Length (in.)9.49
Each Width (in.)7.72
Each Height (in.)7.48
Each Weight (lb.)3.50
Each Cube (CuFt.)0.3171
Pack TypeBox
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923131506
Case Quantity4
Case Length (in.)19.69
Case Width (in.)15.94
Case Height (in.)8.50
Case Weight (lb.)14.00
Case Cube (CuFt.)1.5439
×

Dimmer Compatibility

Type Brand Model Number Website
Dimmer Leviton 66ELV Visit
Dimmer Lutron CTRP-253P Visit
Dimmer Lutron DVRP-253P Visit
Dimmer Lutron MA-PRO Visit
Dimmer Lutron NTRP-250 Visit
Dimmer Lutron RRD-PRO Visit
×
×
