S18410 13T8U6/LED/CCT/DUAL/SE-DE

S18410

13T8U6/LED/CCT/DUAL/SE-DE

13 Watt T8 U-BEND LED; 50000 Hours; Medium Bi Pin Base; CCT Selectable; Type A/B; White Finish; 120-277 Volt


SATCO|NUVO'S LED T8 U-Bend lamps are CCT selectable and available in 1 inch, 3 inch, and 6 inch models to provide versatility in a range of applications. 1 inch and 6 inch models are Dual Mode to operate in ballast bypass or ballast compatible configuration and the 3 inch model is ballast bypass. All lamps can be easily installed with single-ended non-shunted sockets or double-ended shunted or non-shunted sockets. Save at least 40% when using LED U-Bend lamps to replace traditional fluorescent lamps
  • CCT Selectable
  • Dual mode models compatible with ballast or in ballast bypass configurations
  • Shatterproof tube
  • Single or double-ended wiring when installed for ballast bypass operation
  • Compatible with select emergency backup and dimming ballasts
  • 5-Year warranty
  • 6 inch leg spacing
  • Medium Bi Pin base
Lights

S18410

13T8U6/LED/CCT/DUAL/SE-DE

13 Watt T8 U-BEND LED; 50000 Hours; Medium Bi Pin Base; CCT Selectable; Type A/B; White Finish; 120-277 Volt

SATCO|NUVO'S LED T8 U-Bend lamps are CCT selectable and available in 1 inch, 3 inch, and 6 inch models to provide versatility in a range of applications. 1 inch and 6 inch models are Dual Mode to operate in ballast bypass or ballast compatible configuration and the 3 inch model is ballast bypass. All lamps can be easily installed with single-ended non-shunted sockets or double-ended shunted or non-shunted sockets. Save at least 40% when using LED U-Bend lamps to replace traditional fluorescent lamps
  • CCT Selectable
  • Dual mode models compatible with ballast or in ballast bypass configurations
  • Shatterproof tube
  • Single or double-ended wiring when installed for ballast bypass operation
  • Compatible with select emergency backup and dimming ballasts
  • 5-Year warranty
  • 6 inch leg spacing
  • Medium Bi Pin base

Specifications

General
StatusActive
SubstituteS18413
Watts13W
Incandescent Equivalent50W
Fluorescent Equivalent32W
Volts120V-277V
Ballast TypeType A/B
ShapeT8
BaseMedium Bi Pin
ANSI BaseG13
Nominal Length22.5
FinishWhite
CCT (Kelvin)3500K/4000K/5000K
TemperatureNeutral White to Natural Light
CRI80
Lumens1900L/1975L/1950L
Beam Spread160
DimmableYes-Dimmable
Hours Rated50000
Product CategoryU-Bend
Lamp TypeU-Bend
TechnologyLED
Electrical
Watts13W
Incandescent Equivalent50W
Fluorescent Equivalent32W
Volts120V-277V
Ballasting RequirementsBallast required (Type A) or Ballast Bypass (Type B)
Ballast TypeType A/B
Operating Frequency50/60Hz
CCT (Kelvin)3500K/4000K/5000K
TemperatureNeutral White to Natural Light
CRI80
Lumens1900L/1975L/1950L
Beam Spread160
DimmableYes-Dimmable
Dimming NoteOnly in Type A mode; Check Ballast MFG for Dimmer Compatibility
Power Factor0.9
Hours Rated50000
THD20%
Operating Temperature-20C (-4F) to +45C (+113F)
Physical
MOL22.6
MOD1
Nominal Length22.5
Leg Spacing6
ShapeT8
BaseMedium Bi Pin
ANSI BaseG13
FinishWhite
MaterialPlastic
Lens FinishFrost
Lens MaterialPlastic
Housing ColorWhite
Additional Information
Additional InfoReplaces FB32T8/U6
Installation NotesNot for use in vapor tight fixtures.
Rated For Enclosed FixtureYes
Warranty5 Year Limited - T8 LED Bulbs
Compliance
Safety ListingcULus - Listed; cULus - Classified; cETLus - Listed
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDS-R4NQ0V
CA T20 / T24 RationaleExempt - Base Not Regulated
RoHS CompliantYes
FCC CompliantYes
NSF ApprovedYes
Flicker FreeNo
SDS SheetLED Lamp
Packaging
Each UPC045923184109
Each Quantity1
Each Length (in.)23.23
Each Width (in.)7.09
Each Height (in.)1.18
Each Weight (lb.)0.77
Each Cube (CuFt.)0.1125
Pack TypeColor Box
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923184106
Case Quantity12
Case Length (in.)24.41
Case Width (in.)8.27
Case Height (in.)15.16
Case Weight (lb.)9.48
Case Cube (CuFt.)1.7710
×
×

Ballast Compatibility

Name Type View
LED T8 Ballast Compatibility Chart LED T8 Ballasts Ballasts View
×
×

Precautions

No precautions available at this time.

×
