| Company | SATCO |
|---|---|
| Center Beam Candle Power | 9500 |
| Lamp Filament | C-8 |
| Fixture Type | MR |
| Spot Type | NSP - Narrow Spot |
| Status | Obsolete |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | Clear |
| Additional Info | UV Block |
| Amps | 5.417A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | Clear |
| Lensed | Yes |
| Operating Position | Universal |
| SDS Class | Halogen_Double_Ended_or_Pin_Based_Lamp |
| Product Technology | Halogen |
| CCT (Kelvin Temp) | 2900K |
|---|---|
| Dimmable | Yes-Dimmable |
| Hours Rated | 2000 |
| Beam Angle (degree) | 9 |
| Color Temp | Warm White |
| CRI | 100 |
| Dimming Type | Check the transformer/driver MFG for dimmer compatibility |
| Lumens | 630L |
| Volts | 12V |
| Watts | 65W |
| Lamp Base | Miniature 2 Pin Round |
|---|---|
| Finish | Clear |
| ANSI Base | GU5.3/GX5.3 |
| Lamp Type | MR16 |
| MOD Lamps | 2.0 |
| MOL | 1.88 |
| CA T20 Compliant Substitute | S8636 |
|---|---|
| Location Rating | Damp |
| MA Alt Sub | S8636 |
| NV Alt Sub | S8636 |
| ROHS Compliant | Yes |
| Safety Listing | Not Applicable |
| California Ban | Non-Compliant |
| DLC Approved | No |
| Title 20 | No |
| T24/JA8 Compliant | No |
| US State Ban | CA, MA, NV |
| UPC | 045923019692 |
|---|---|
| Case Cube | 1.5894 |
| Case Height | 11.82 |
| Case Length | 17.34 |
| Case Quantity | 240 |
| Case UPC | 10045923019699 |
| Case Weight | 23.81 |
| Case Width | 13.4 |
| EA Cube | 0.0047 |
| EA Height | 2.01 |
| EA Length | 2.01 |
| EA Quantity | 1 |
| EA Weight | 0.09 |
| EA Width | 2.01 |
| Inner Cube | 0.0676 |
| Inner Height | 2.17 |
| Inner Length | 8.39 |
| Inner Quantity | 12 |
| Inner UPC | 20045923019696 |
| Inner Weight | 1.17 |
| Inner Width | 6.42 |
| Pack Type | Box |
| Web Length | 1.88 |
| Web Width | 2.0 |
