9.5T8L48/835/B/GF/U/MX - S19901MX
9.5T8L48/835/B/GF/U/MX - S19901MX
9.5T8L48/835/B/GF/U/MX - S19901MX
9.5T8L48/835/B/GF/U/MX - S19901MX
9.5T8L48/835/B/GF/U/MX - S19901MX
9.5T8L48/835/B/GF/U/MX - S19901MX
S19901MX

9.5T8L48/835/B/GF/U/MX

  • 9.5 Watt
  • 48-Inch T8 LED
  • G13 Base
  • 3500K CCT
  • Type B
  • Frost Finish
  • 120-277 Volt
location_rating^damp^1
lamp_ballast_type_ab^type_b^1
ip_rating^IP20^1
hours_rated^50k^2
warranty^5_years^2
volts^120-277v^2
fcc_compliant^true^3
rohs_compliant^y^3
nsf_approved^y^3
Description
Description
The SATCO NUVO S19901MX is a TAA compliant 4-foot LED lamp designed to meet the requirements of government-funded projects, including GSA applications and other opportunities where TAA compliance is essential. This 9.5-watt medium bi-pin lamp delivers a neutral 3500K color temperature and serves as an energy-efficient replacement for traditional T8 and T12 fluorescent lamps. Engineered for ballast bypass installation with single or double-ended wiring configurations, it provides dependable performance, immediate energy savings, and reduced maintenance for schools, healthcare facilities, public buildings, and commercial environments.
Products Specs
General
CompanySATCO
Lamp Ballast Type ABType B
MaterialGlass / Polycarbonate (PC)
Fixture TypeLinear
StatusActive
Surge ProtectionBuilt-in surge protection - 1KV
Total Harmonic Distortion<25%
CCT SelectableNo
Wattage SelectableNo
Finish FamilyWhite
Amps0.091-0.035A
Nominal Length48.0
Operating PositionUniversal
Power Factor>0.9
SDS ClassLED_Lamp
Indoor OutdoorIndoor
Product TechnologyLED
Fluor Equiv25W/28W/30W/32W
Serviceable BatteryNo
Electrical
CCT (Kelvin Temp)3500K
DimmableNon-Dimmable
Hours Rated50000
Beam Angle (degree)210
Color TempNeutral White
CRI80+
Operating Frequency50/60Hz
Operating Temp-4F to +113F (-20C to +45C)
Lumens1600L
Volts120V-277V
Watts9.5W
Physical
Lamp BaseMedium Bi Pin
FinishFrost
ANSI BaseG13
Lamp TypeT8
MOD Lamps1.0
MOL47.75
Additional Info
Warranty5-Years
Rated For Enclosed FixtureNo
Features
Flicker FreeNo
Compliance
Air TightNo
CA Prop 65Lead
Dark Sky RatedNo
DLC IDS-3BY149
FCC CompliantYes
IP RatingIP20
Location RatingDamp
NSF ApprovedYes
ROHS CompliantYes
Safety ListingcRUus - Recognized Component, cUL - Certified, cUL - Classified
California BanLawful for sale
DLC ApprovedYes
Title 20Exempt
T24/JA8 CompliantNo
Packaging
UPC045923414466
Case Cube0.9909
Case Height5.87
Case Length48.78
Case Quantity25
Case UPC10045923414463
Case Weight13.6
Case Width5.98
EA Cube0.0335
EA Height1.1
EA Length47.78
EA Quantity1
EA Weight0.49
EA Width1.1
Web Length47.75
Web Width1.0
