| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type A |
| Ballasting Requirements | Ballast required, check compatibility |
| Lamp Filament | LED |
| Fixture Type | PL |
| Status | Discontinued |
| Style | Transitional |
| Most Current Generation | S21412 |
| Total Harmonic Distortion | 20% |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | White |
| Amps | 0.133-0.058A |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | Frost |
| Lensed | True |
| Operating Position | Base Up or Down |
| Power Factor | 0.9 |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Fluor Equiv | 42W |
| Incandescent Equivalent | 100W |
| CCT (Kelvin Temp) | 3500K |
|---|---|
| Hours Rated | 50000 |
| Beam Angle (degree) | 110 |
| Color Temp | Neutral White |
| CRI | 80+ |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Lumens | 1750L |
| Volts | Ballast Dependent |
| Watts | 16W |
| Lamp Base | G24q (4-Pin) |
|---|---|
| Finish | Frost |
| ANSI Base | G24q |
| Lamp Type | PL |
| MOD Lamps | 3.75 |
| MOL | 5.19 |
| Warranty | 5-Years |
|---|---|
| Rated For Enclosed Fixture | True |
| CA Regulations | Exempt - Base Not Regulated |
|---|---|
| CA Status | Lawful for sale in California |
| CO Status | Lawful for sale |
| DLC ID | PLS86H65T77J |
| FCC Compliant | True |
| HI Status | Lawful for sale |
| Location Rating | Damp |
| NV Status | Lawful for sale |
| NSF Approved | Yes |
| ROHS Compliant | Yes |
| Safety Listing | cULus |
| CA Compliance Text | Lawful for sale |
| VT Status | Lawful for sale |
| WA Status | Lawful for sale |
| DLC Approved | True |
| Title 20 | Exempt |
| UPC | 045923224058 |
|---|---|
| Case Cube | 1.5156 |
| Case Height | 14.17 |
| Case Length | 20.86 |
| Case Quantity | 20 |
| Case UPC | 10045923224055 |
| Case Weight | 11.68 |
| Case Width | 8.86 |
| EA Cube | 0.0543 |
| EA Height | 6.3 |
| EA Length | 3.86 |
| EA Quantity | 1 |
| EA Weight | 0.33 |
| EA Width | 3.86 |
| Inner Cube | 0.6439 |
| Inner Height | 6.7 |
| Inner Length | 20.08 |
| Inner Quantity | 10 |
| Inner UPC | 20045923224052 |
| Inner Weight | 5.5 |
| Inner Width | 8.27 |
| Pack Type | Box |
| Web Length | 5.19 |
| Web Width | 3.75 |
