| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type A |
| Ballasting Requirements | For Use With Electronic Ballasts |
| Fixture Type | Circline |
| Status | Obsolete |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | White |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | Frost |
| Lensed | Yes |
| Nominal Length | 9.0 |
| Operating Position | Universal |
| SDS Class | Linear_Fluorescent_Lamp |
| Product Technology | Fluorescent |
| CCT (Kelvin Temp) | 3500K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 12000 |
| Beam Angle (degree) | 360 |
| Color Temp | Neutral White |
| CRI | 80+ |
| Operating Temp | Ballast Dependent |
| Lumens | 1800L |
| Watts | 22W |
| Lamp Base | 2GX13 (4-Pin) |
|---|---|
| Finish | Frost |
| Housing Color | None |
| ANSI Base | 2GX13 |
| Lamp Type | T5 |
| MOD Lamps | 0.63 |
| MOL | 9.0 |
| Warranty | 3-Years |
|---|---|
| Installation Notes | Outer Diameter is 9 inches |
| CA Prop 65 | Lead |
|---|---|
| ROHS Compliant | Yes |
| Safety Listing | Not Applicable |
| California Ban | Non-Compliant |
| DLC Approved | No |
| Title 20 | No |
| T24 Compliant | No |
| US State Ban | CA, CO, HI, ME, MN, OR, RI, VT |
| UPC | 046135207129 |
|---|---|
| Case Cube | 0.8285 |
| Case Height | 10.0 |
| Case Length | 14.76 |
| Case Quantity | 12 |
| Case UPC | 10046135207126 |
| Case Weight | 4.03 |
| Case Width | 9.7 |
| EA Cube | 0.0475 |
| EA Height | 9.06 |
| EA Length | 9.06 |
| EA Quantity | 1 |
| EA Weight | 0.25 |
| EA Width | 1.0 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Box |
| Web Length | 9.0 |
| Web Width | 0.63 |
