| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type B |
| Ballasting Requirements | Ballast Bypass |
| Lamp Filament | LED |
| Fixture Type | Corncob |
| Status | Discontinued |
| Most Current Generation | S39769 |
| Surge Protection | Built-in surge protection - 3KV |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | No Finish |
| Additional Info | Width 360 deg 4.2 in.; Width 270 deg 9.3 in.; Width 180 deg 10.9 in. Approved for totally enclosed fixtures; Base up or base down operation; For outdoor & indoor use; Emits no UV light / Contains no Mercury (Hg) |
| Amps | 0.750-0.271A |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | Clear |
| Lensed | True |
| Minimum Compartment Size | Length: 8.27 in. Width: 9.25 in. Depth: 9.25 in. |
| Operating Position | Base Up or Down |
| Power Factor | >0.9 |
| SDS Class | LED_Lamp |
| Indoor Outdoor | Indoor, Outdoor |
| Product Technology | LED |
| Fluor Equiv | 105W |
| Incandescent Equivalent | 750W |
| CCT (Kelvin Temp) | 5000K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 360 |
| Color Temp | Natural Light |
| CRI | 80+ |
| Operating Frequency | 50/60Hz |
| Operating Temp | -25C (-13F) to +45C (+113F) |
| HID Equivalent | 400W |
| Lumens | 9800L |
| Volts | 120V-277V |
| Watts | 75W |
| Lamp Base | Mogul Extended |
|---|---|
| Finish | Clear |
| Housing Color | White |
| ANSI Base | EX39 |
| Lamp Type | Corncob |
| MOD Lamps | 4.19 |
| MOL | 8.63 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. Arms fully open diameter is 10.88 inches |
| Rated For Enclosed Fixture | True |
| CA Regulations | Exempt - Base Not Regulated |
|---|---|
| CA Status | Lawful for sale in California |
| CO Status | Lawful for sale |
| FCC Compliant | True |
| HI Status | Lawful for sale |
| IP Rating | IP65 |
| Location Rating | Damp |
| NV Status | Lawful for sale |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Classified, cULus - Listed |
| CA Compliance Text | Lawful for sale |
| VT Status | Lawful for sale |
| WA Status | Lawful for sale |
| DLC Approved | False |
| Title 20 | Exempt |
| T24 Compliant | False |
| UPC | 045923297694 |
|---|---|
| Case Cube | 2.9308 |
| Case Height | 11.81 |
| Case Length | 24.2 |
| Case Quantity | 12 |
| Case UPC | 10045923297691 |
| Case Weight | 41.76 |
| Case Width | 17.72 |
| EA Cube | 0.1654 |
| EA Height | 9.84 |
| EA Length | 5.39 |
| EA Quantity | 1 |
| EA Weight | 3.11 |
| EA Width | 5.39 |
| Inner Cube | 1.2319 |
| Inner Height | 10.83 |
| Inner Length | 16.93 |
| Inner Quantity | 6 |
| Inner UPC | 20045923297698 |
| Inner Weight | 20.06 |
| Inner Width | 11.61 |
| Pack Type | Box |
| Web Length | 8.63 |
| Web Width | 4.19 |
