| Company | SATCO |
|---|---|
| Bulb Included | Integrated |
| Material | Thermo Plastic (PBT) |
| Fixture Type | Downlight Retrofit |
| Status | Discontinued |
| Most Current Generation | S11820R1 |
| CCT Selectable | False |
| Wattage Selectable | False |
| Can Size | 4 in. |
| Finish Family | White |
| Additional Info | Trim material is Thermo Plastic; Trim color is White |
| Amps | 0.058A |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | Frost |
| Lens Material | Plastic (PS) |
| Power Factor | 0.95 |
| SDS Class | LED_Fixture |
| Indoor Outdoor | Indoor |
| Product Technology | LED |
| Incandescent Equivalent | 50W |
| CCT (Kelvin Temp) | 4000K |
|---|---|
| Dimmable | Yes-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 90 |
| Color Temp | Cool White |
| CRI | 90+ |
| Dimming Type | Forward Phase or Reverse Phase or Phase Selectable |
| Operating Frequency | 60Hz |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Lumens | 600L |
| Volts | 120v |
| Watts | 7W |
| Lamp Base | Medium Adapter |
|---|---|
| Finish | WHITE |
| ANSI Base | E26 Adapter |
| Lamp Type | Integrated LED |
| Fixture Shape | Square |
| Warranty | 5-Years |
|---|
| CA Regulations | California T24 2016 - 2025 JA8 Listed; T20 Listed |
|---|---|
| CA Prop 65 | Lead |
| CA Status | Lawful for sale in California |
| FCC Compliant | True |
| IC Rated | True |
| Location Rating | Wet |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Classified |
| CA Compliance Text | California T24 Listed |
| DLC Approved | False |
| Energy Star Certified | No |
| Title 20 | Yes |
| T24 Compliant | True |
| UPC | 045923397585 |
|---|---|
| Case Cube | 1.7926 |
| Case Height | 6.69 |
| Case Length | 25.91 |
| Case Quantity | 24 |
| Case UPC | 10045923397582 |
| Case Weight | 17.6 |
| Case Width | 17.87 |
| EA Cube | 0.06 |
| EA Height | 5.91 |
| EA Length | 5.71 |
| EA Quantity | 1 |
| EA Weight | 0.62 |
| EA Width | 3.07 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Box |
| Web Height | 2.75 |
| Web Length | 5.31 |
| Web Width | 5.31 |
